Siemens 3TB4222-0XC2 Contactor 24V AC Coil, 16A, 7.5kW, 1 NO + 1 NC, Size 1, Screw Connection Original Brand New

Overview

The Siemens 3TB4222-0XC2 is a high-performance AC contactor designed for reliable switching of electrical loads. This robust and compact device is an essential component for motor control, automation, and industrial applications. Built to Siemens’ exacting quality standards, it ensures long-term operational stability and safety in demanding environments. The 3TB4222-0XC2 is part of the trusted Siemens SIRIUS series, known for its modular design and exceptional durability.

Key Features & Technical Specification

• Operating Voltage: AC 50/60 Hz
• Coil Voltage: 24V AC
• Rated Operational Current (AC-3): 16 A at 400 V
• Rated Power (AC-3): 7.5 kW at 400 V
• Auxiliary Contacts: 1 Normally Open (NO) + 1 Normally Closed (NC)
• Size: Size 1
• Connection Type: Screw terminals for secure and reliable wiring
• Mounting: Standard DIN rail or screw mounting
• Standards: IEC 60947, EN 60947

Benefit

• Reliable Performance: Engineered for high-frequency switching and long operational life, reducing maintenance and downtime.
• Enhanced Safety: Features a built-in auxiliary contact configuration (1 NO + 1 NC) for versatile control and signaling applications, improving system safety and monitoring capabilities.
• Easy Installation: The compact size and screw connection terminals simplify installation and maintenance, saving time and labor costs.
• Versatile Application: Ideal for a wide range of industrial uses, including motor starting, lighting control, and heating systems.
• Genuine Siemens Quality: Manufactured by Siemens, a global leader in industrial automation, guaranteeing quality, compatibility, and support.

Function

The Siemens 3TB4222-0XC2 contactor functions as an electrically operated switch. When the 24V AC coil is energized, it closes the main power contacts, allowing current to flow to the connected load, such as an electric motor. The auxiliary contacts simultaneously change their state (NO becomes closed, NC becomes open), providing feedback or control signals to other parts of the system, such as PLCs, indicator lights, or interlock circuits. De-energizing the coil opens the main and auxiliary contacts, safely disconnecting the load.

Application

• Motor control and starting
• Pump and fan control
• HVAC systems
• Lighting control panels
• Industrial machinery
• Automation systems
