Siemens 3TB4222-0XG2 Contactor – 110V AC, 16A, 7.5kW, 1 NO + 1 NC Auxiliary Contact Original Brand New

Overview

The Siemens 3TB4222-0XG2 is a robust and reliable AC contactor designed for a wide range of industrial and commercial applications. This Size 1 contactor is engineered to handle demanding electrical loads with exceptional efficiency and safety. It operates on a 50/60 Hz frequency and features a control voltage of 110V AC. With a rated operational current of 16A at 400V AC and a power rating of 7.5 kW, this contactor is ideal for controlling motors, heating elements, and other inductive loads. Its compact design and screw connection terminals make installation and wiring straightforward and secure.

Key Features & Specification

• Product Number: 3TB4222-0XG2
• Operating Frequency: 50/60 Hz
• Control Voltage: 110V AC
• Rated Operational Current (Ie​): 16 A (at 400V, AC-3)
• Rated Power (Pe​): 7.5 kW (at 400V, AC-3)
• Auxiliary Contacts: 1 Normally Open (NO) + 1 Normally Closed (NC)
• Contactor Size: Size 1
• Connection Type: Screw Connection
• Standard: Compliant with IEC and other relevant international standards.

Benefit

• High Performance and Durability: Built with high-quality materials, the Siemens 3TB4222-0XG2 offers a long mechanical and electrical life, reducing the need for frequent replacements.
• Enhanced Safety: The integrated auxiliary contacts (1 NO + 1 NC) provide flexible options for interlocking, status indication, and control circuit functions, improving overall system safety.
• Efficient Power Management: Designed for efficient switching of power circuits, helping to reduce energy consumption and operational costs.
• Easy Installation: The screw connection terminals ensure a firm and reliable electrical connection, while the compact design saves valuable space within control panels and enclosures.
• Versatile Application: Suitable for a broad spectrum of applications, including motor control, lighting systems, heating systems, and general industrial automation.

Function

The Siemens 3TB4222-0XG2 contactor's primary function is to switch an electrical power circuit on or off. When the 110V AC coil is energized, the main contacts close, allowing current to flow to the connected load. The auxiliary contacts simultaneously change their state (NO closes, NC opens), providing signals for control and monitoring circuits. This makes it an essential component for automated control systems, providing the interface between low-power control signals and high-power electrical loads.

Application

• Motor control for pumps, fans, conveyors, and compressors
• HVAC systems
• Industrial machinery
• Lighting control in large facilities
• Heating element control
• Automation and control panels
