Siemens 3TY7543-0XJ1 Contactor Coil Spare Part for 3TF54/55, AC 60Hz 115V / 50Hz 96V Original Brand New

Overview

The Siemens 3TY7543-0XJ1 is a high-quality, genuine spare part coil designed specifically for the Siemens 3TF54 and 3TF55 contactors. This essential component is crucial for the proper functioning of your contactor, responsible for creating the magnetic field that closes the main contacts. By replacing a worn or damaged coil with the 3TY7543-0XJ1, you can restore your contactor’s operational reliability and extend its service life. This coil is engineered for versatility, accommodating both 60 Hz and 50 Hz AC power systems with voltage ratings of 115 V and 96 V, respectively.

Key Features & Benefit

• Genuine Siemens Quality: Manufactured to the same high standards as the original equipment, ensuring perfect fit, form, and function.
• Reliable Performance: Guarantees consistent and dependable operation of your 3TF54/55 contactor, preventing unexpected downtime.
• Dual-Frequency Compatibility: Designed to work seamlessly in both 115 V AC (60 Hz) and 96 V AC (50 Hz) electrical systems, offering flexibility and broad application use.
• Cost-Effective Solution: Provides a cost-efficient alternative to replacing the entire contactor, saving you money on maintenance and repairs.
• Easy Installation: Engineered for a straightforward replacement process, minimizing labor time and getting your equipment back online faster.
• Extended Equipment Lifespan: Regular maintenance and replacement of key components like the coil can significantly prolong the life of your Siemens contactor.

Technical Specification

• Product Number: 3TY7543-0XJ1
• Product Type: Contactor Spare Part Coil
• Compatible Contactors: Siemens 3TF54, 3TF55
• Voltage (AC):
  • 115 V (at 60 Hz)
  • 96 V (at 50 Hz)
• Frequency: 50 Hz, 60 Hz
• Manufacturer: Siemens
• Application: Replacement coil for contactors in motor control, power switching, and other industrial applications.

Function

The coil is the heart of an electromechanical contactor. When an electrical current is applied to the coil’s windings, it generates a magnetic field. This field pulls the armature, which in turn causes the main contacts to close, allowing power to flow to the connected load (e.g., an electric motor). The Siemens 3TY7543-0XJ1 coil is precisely engineered to provide the correct magnetic force for the 3TF54/55 series, ensuring smooth and reliable contact operation. A faulty or weak coil can lead to contact chattering, welding, or failure to close, making a genuine replacement essential for safe and efficient operation.
