Siemens 5SD480 SILIZED Fuse Link, 500V, 30A, Quick-Acting, Size DII Original Brand New

Model / SKU5SD480

High-performance SILIZED fuse link designed for the ultra-rapid protection of power semiconductors. Operating at 30A and 500V, this Size DII fuse features an E27 thread and quick-acting characteristics to prevent damage to sensitive electronic components.

$10.52
In stockShips in 1–3 business days
  • ConditionOriginal Brand New
  • Warranty12 months
Request bulk quoteAsk on WhatsApp
  • Genuine Products
  • Up to 1-Year Warranty
  • Global Shipping
  • Secure Payment
  • PI / Bank Transfer Available
  • Bulk Quote Support

Description

Overview

The Siemens 5SD480 SILIZED Fuse Link is a high-performance quick-acting fuse designed specifically for semiconductor protection. Rated at 500 V and 30 A, this fuse provides fast and reliable disconnection in the event of overcurrent, helping to protect sensitive electronic and power semiconductor components.

Manufactured to Siemens’ high quality standards, the fuse link features a DII size with E27 screw cap, ensuring compatibility with standard fuse bases and easy installation in industrial and commercial electrical systems.

Key Benefit

  • Ultra-Fast Response: Quick-acting (gR) characteristic specifically tuned for semiconductor protection.

  • Standardized Fitting: Size DII with an E27 screw base ensures compatibility with standard fuse bases.

  • Siemens Reliability: Built to rigorous international standards for consistent tripping performance.

  • High Breaking Capacity: Safely interrupts high-fault currents in industrial environments.

Application

  • Power converters and rectifiers.

  • UPS systems and frequency inverters.

  • Industrial motor control centers.

  • Protection of sensitive power electronics.

Technical Specification

  • Brand: Siemens

  • Product Number: 5SD480

  • Fuse Type: SILIZED fuse link

  • Voltage Rating: 500 V

  • Current Rating: 30 A

  • Fuse Characteristic: Quick-acting

  • Size: DII

  • Base Type: E27

  • Application: Semiconductor protection

Visit 5SD480 for more detail info

For more our products visit turll

Download

Datasheet in PDF

Specifications

SKU / Model5SD480
BrandSIEMENS
product brand nameSENTRON
product designationDIAZED fuse
design of the productfor semiconductor protection
design of the fuse linkSILIZED fuse link, DIAZED design
tripping characteristic classquick-acting (FE)
size of fuse system / acc. to DIN EN 60269-1DII
operating class of the fuse linkgR
supply voltage / at DC500 V
protection class IPIP20, with connected conductors
switching capacity current / at DC / acc. to IEC 60947-2 / rated value8 kA
power loss [W]13.4 W
power loss [W] / for rated value of the current / at AC / in hot operating state / per pole13.4 W
operational current-
● at AC / rated value30 A
color coding of the fuse linkothers
product descriptionUsing screw adapter or adapter sleeves
mounting positionAny, preferably vertical
ambient temperature / during operation-
● minimum-5 °C
● maximum40 °C
environmental categoryUp to 45°C at 95 % rel. humidity
Weight0.031 kg
Dimensions25.00 × 111.00 × 51.00 mm
