Siemens 5SE2325 NEOZED Fuse-Link D02 25A, gG, 400V AC / 250V DC Tin-Coated Contacts
Siemens 5SE2325 NEOZED Fuse-Link D02 25A, gG, 400V AC / 250V DC Tin-Coated Contacts
Siemens 5SE2325 NEOZED Fuse-Link D02 25A, gG, 400V AC / 250V DC Tin-Coated Contacts
Siemens 5SE2325 NEOZED Fuse-Link D02 25A, gG, 400V AC / 250V DC Tin-Coated Contacts
Siemens 5SE2325 NEOZED Fuse-Link D02 25A, gG, 400V AC / 250V DC Tin-Coated Contacts

SIEMENS

Siemens 5SE2325 NEOZED Fuse-Link D02 25A, gG, 400V AC / 250V DC Tin-Coated Contacts Original Brand New

Model / SKU5SE2325

High-performance NEOZED fuse-link designed for superior circuit protection. Featuring a 25A current rating and D02 size, this gG-class fuse includes tin-coated contact caps for enhanced conductivity and corrosion resistance. Suitable for both 400V AC and 250V DC applications.

$3.81
In stockShips in 1–3 business days
  • ConditionOriginal Brand New
  • Warranty12 months
Request bulk quoteAsk on WhatsApp
  • Genuine Products
  • Up to 1-Year Warranty
  • Global Shipping
  • Secure Payment
  • PI / Bank Transfer Available
  • Bulk Quote Support

Description

Overview

The Siemens 5SE2325 NEOZED Fuse-Link is a high-quality D02 fuse designed for reliable overcurrent protection in low-voltage electrical installations. Rated at 25 A, this gG general-purpose fuse ensures dependable protection for cables, conductors, and electrical equipment. Featuring tin-coated contact caps, it delivers excellent conductivity, corrosion resistance, and long service life in demanding industrial and commercial environments.

Benefit

  • Space-Saving Design: Much smaller than older DIAZED systems, allowing for more compact distribution boards.

  • Corrosion Resistance: Features tin-coated contact caps to ensure long-term electrical reliability and prevent oxidation.

  • Dual Voltage Rating: Versatile operation in both AC (400V) and DC (250V) environments.

  • Lower Power Heat Dissipation: Engineered for high energy efficiency and low heat generation during operation.

Function

  • Protects electrical circuits against overloads and short circuits

  • Ensures safe operation of low-voltage distribution systems

  • Suitable for use in control panels, distribution boards, and switchgear

  • Designed for general-purpose (gG) full-range protection

Technical Specification

  • Fuse Type: NEOZED fuse-link

  • Size: D02

  • Rated Current: 25 A

  • Utilization Category: gG

  • Rated Voltage (AC): 400 V

  • Rated Voltage (DC): 250 V

  • Contact Caps: Tin-coated

  • Manufacturer: Siemens

Visit 5SE2325 for more detail info

For more our products visit turll

Download

Datasheet in PDF

Specifications

SKU / Model5SE2325
BrandSIEMENS
product brand nameSENTRON
product designationNEOZED fuse link
design of the productWith tin-coated contact caps
product variationsPack of 10
design of the fuse linkNEOZED fuse link
size of fuse system / acc. to DIN EN 60269-1D02
operating class of the fuse linkgG
supply voltage-
● at DC250 V
operating voltage / rated value400 V
protection class IPIP20, with connected conductors
switching capacity current / acc. to IEC 60947-2 / rated value50 kA
power loss [W] / for rated value of the current / at AC / in hot operating state / per pole1.7 W
operational current-
● at 30 °C / rated value24.5 A
● at 40 °C / rated value23.75 A
● at 45 °C / rated value23 A
● at 50 °C / rated value22.5 A
● at 55 °C / rated value22 A
● at 60 °C / rated value21.5 A
● at AC / rated value25 A
operational current / rated value25 A
color coding of the fuse linkYellow
breaking capacity maximum short-circuit current (Icu) / at AC / rated value50 kA
mounting positionAny, preferably vertical
ambient temperature / during operation-
● minimum40 °C
● maximum40 °C
environmental categoryUp to 45°C at 95 % rel. humidity
Test Certificatesother
Weight0.012 kg
Dimensions32.00 × 81.00 × 38.00 mm
