Siemens 5ST3740 Pin Busbar, Touch-Safe, 10 mm², 3-Phase, 1016 mm, Cuttable Original Brand New
$24.09
Pin busbar touch-safe, 10 mm² 3-phase, 1016 mm long, cuttable, without end caps – reliable Siemens quality for safe and efficient electrical distribution.
Availability: In stock
Overview
The Siemens 5ST3740 Pin Busbar is an essential component for modern electrical installations, providing a reliable and compact method for connecting circuit breakers and other modular devices. As part of the Siemens SENTRON family, it ensures high conductivity and superior safety standards. Its cuttable design allows it to be adapted to any panel size, making it a versatile choice for industrial and residential distribution boards.
Benefit
-
Customizable Length: The 1016 mm bar can be easily cut to fit specific enclosure sizes or pole requirements.
-
Enhanced Safety: Built with touch-safe protection to prevent accidental contact with live parts.
-
Space Efficient: Reduces clutter within the distribution board compared to individual wire jumpers.
-
Reliable Connectivity: Ensures low-resistance power distribution across multiple 3-phase circuits.
Technical Function
-
Phase Connection: 3-Phase distribution for balanced electrical loading.
-
Conductivity: 10 mm² cross-section rated for standard industrial and commercial current loads.
-
Modular Compatibility: Designed for use with MCBs (Miniature Circuit Breakers) and other DIN-rail mounted devices.
-
Flexibility: Supplied without end caps to allow for precision cutting and finishing.
Visit 5ST3740 for more detail info
For more our products visit turll
Download
| Weight | 0.430 kg |
|---|---|
| Dimensions | 80.00 × 1020.00 × 80.00 mm |
| Brand | SIEMENS |
| product brand name | SENTRON |
| product designation | Pin busbar |
| design of the product | 10 mm², 3PH L1016 mm |
| phase number | 3 |
| cross-section | 10 mm² |
| operational current / rated value | 63 A |
| product feature / insulated | Yes |
| type of electrical connection | Pin |
| length | 1 016 mm |
