Siemens 5SV1316-6KK16 RCBO Compact, 1 MW, 1-Pole+N, 6 kA, Type A, 30 mA, B16 Original Brand New

Overview

The Siemens 5SV1316-6KK16 RCBO is a high-performance compact residual current circuit breaker with overcurrent protection (RCBO). Designed for residential, commercial, and industrial electrical installations, this device combines protection against short circuits, overloads, and earth leakage currents in a single unit. Its 1-pole+N configuration, rated 16A (B16), and 30 mA Type A residual current sensitivity ensure reliable safety for both people and equipment. With a 6 kA breaking capacity, it is ideal for medium-load circuits up to 1 MW, offering long-term durability and performance.

Benefit

• Enhanced Safety: Protects against short circuits, overloads, and leakage currents simultaneously.

• Compact Design: Saves space in distribution boards without compromising performance.

• Reliable Operation: 6 kA breaking capacity ensures safe disconnection in high-demand scenarios.

• Type A Sensitivity: Detects both AC and pulsating DC leakage currents, ideal for modern appliances.

• Easy Installation: 1-pole+N design simplifies wiring and maintenance.

Functions & Features

• Rated current: B16

• Residual current sensitivity: 30 mA, Type A

• Short-circuit capacity: 6 kA

• Pole configuration: 1-pole + Neutral (N)

• Compact modular design for DIN rail mounting

• Conforms to IEC/EN 61009 standards

• Suitable for residential, commercial, and light industrial circuits

Technical Specification

• Product Number: 5SV1316-6KK16

• Rated voltage: 230/400 V AC

• Rated current: 16 A

• Tripping characteristics: Type B

• Residual current: 30 mA, Type A

• Breaking capacity: 6 kA

• Mounting: DIN rail

Download

Datasheet in PDF
