Siemens 5SV1316-7KK16 RCBO Compact 1 MW, 1-Pole+N, 6 kA, Type A, 30 mA, C16 Original Brand New

Overview

The Siemens 5SV1316-7KK16 RCBO (Residual Current Circuit Breaker with Overcurrent Protection) is a high-performance compact device designed for reliable electrical safety. With a 1 MW rating, 1-pole+N configuration, 6 kA short-circuit capacity, and Type A 30 mA sensitivity, this RCBO ensures optimum protection for both people and electrical installations. Perfect for residential, commercial, and industrial applications, it combines overcurrent and residual current protection in a single compact unit, simplifying installation and reducing maintenance costs.

Benefit

• Dual Protection: Protects against overcurrent (overload and short circuit) and residual current simultaneously.

• Enhanced Safety: Type A 30 mA sensitivity ensures effective protection against AC and pulsating DC fault currents.

• Compact Design: Saves space in distribution boards while providing high-performance protection.

• Reliable Performance: 6 kA breaking capacity suitable for modern electrical systems.

• Easy Installation: User-friendly design for quick mounting and wiring.

Function / Features

• Rated operational current: C16 (16A)

• Pole configuration: 1P+N

• Rated residual operating current: 30 mA

• Rated short-circuit breaking capacity: 6 kA

• Type A protection: sensitive to both AC and pulsating DC currents

• Compact modular design for DIN rail mounting

• Long service life with robust construction

Visit 5SV1316-7KK16 for more detail info

For more our products visit turll

Download

Datasheet in PDF
