Siemens 6ES7134-6JD00-0CA1 SIMATIC ET 200SP Analog Input Module AI 4xRTD/TC Original Brand New

Overview

The Siemens 6ES7134-6JD00-0CA1 is a high-performance SIMATIC ET 200SP Analog Input Module designed for precise temperature measurement and signal processing. As a "High Feature" (HF) module, it supports up to 4 channels for Resistance Temperature Detectors (RTD) or Thermocouples (TC).

This module is engineered for versatility, offering 16-bit resolution and a high accuracy of ±0.1%, making it ideal for demanding industrial automation environments where thermal stability is critical.

Key Benefit & Features

• High Precision: Features a 16-bit resolution with an extremely low error limit of +/-0.1% for reliable data acquisition.

• Versatile Connectivity: Supports 2-wire, 3-wire, and 4-wire connections, providing flexibility for various sensor types.

• Advanced Diagnostics: Includes channel-level diagnostics to quickly identify wire breaks, short circuits, or overflow/underflow errors, reducing downtime.

• Compact Design: Compatible with BaseUnit (BU) types A0 and A1, featuring color code CC00 for easy identification and installation.

• High Feature (HF) Performance: Delivers superior interference rejection and faster cycle times compared to standard modules.

Technical Function

• Signal Evaluation: Expertly processes signals from thermocouples and resistance thermometers.

• Internal Compensation: Optimized for temperature compensation to ensure stable readings in fluctuating ambient conditions.

• Scalability: Integration into the distributed I/O system ET 200SP allows for space-saving cabinet builds.

Download

Datasheet in PDF
