Siemens 6ES7365-0BA01-0AA0 SIMATIC S7-300 IM 365 Interface Module Original Brand New

Overview

The Siemens 6ES7365-0BA01-0AA0 (IM 365) is a dedicated interface solution for the SIMATIC S7-300 PLC system. It allows for the seamless expansion of your automation setup by connecting a single extension rack (ER) to the central rack (CR). This module is the ideal choice for applications that require additional I/O capacity without the need for a communication bus between racks.

Key Benefit

• Plug-and-Play Expansion: Easily increase your I/O point count by adding an extra rack.

• Cost-Effective: A more affordable alternative to the IM 360/361 series for single-rack expansions.

• Complete Kit: Comes as a pair (send/receive modules) including a pre-assembled 1m connecting cable.

• Space Saving: Compact S7-300 design integrates perfectly into standard DIN rail setups.

Function & Application

The IM 365 is used to transfer the backplane bus signals from the central controller to the extension rack.

• Distance: Supports a fixed distance of 1 meter via the included cable.

• Limitations: Note that the IM 365 does not support the P-bus (communication bus); therefore, FM and CP modules requiring a communication bus cannot be used in the extension rack connected via IM 365.

• Power Supply: The extension rack is powered directly from the central rack via the IM 365.

Technical Specification

• Model: IM 365

• Part Number: 6ES7365-0BA01-0AA0

• Compatibility: SIMATIC S7-300 Series

• Included Components: 2 Interface Modules + 1m Connecting Cable

• Current Consumption: Max 100mA from backplane bus 5V DC
