Overview
Siemens 6ES7521-1BH50-0AA0 is a high-performance SIMATIC S7-1500 digital input module designed for reliable signal acquisition in industrial automation systems. This module features 16 digital inputs operating at 24 V DC, optimized for sourcing input signals and compliant with IEC 61131 input type 3 standards.
Engineered for seamless integration into S7-1500 PLC environments, this Basic Automation (BA) module ensures fast response times with an input delay of just 3.2 ms, making it ideal for time-critical control applications. Front connectors (screw terminals or push-in type) are available separately, offering flexible installation options.
Key Benefit
-
Seamless Integration: Fully compatible with the TIA Portal and SIMATIC S7-1500 controllers.
-
Space Efficient: 16 channels in a single module optimize cabinet space.
-
Industrial Durability: Built to withstand harsh factory conditions, complying with IEC 61131 standards.
-
Flexible Wiring: Supports both screw terminals and push-in front connectors (sold separately) for easy installation.
Function & Technical Features
-
Input Type: Sourcing input (M-reading).
-
Input Delay: Fixed at 3.2 ms for stable signal recognition.
-
Input Voltage: Rated 24 V DC.
-
Module Class: Basic (BA) for cost-effective digital monitoring.
-
Hardware Requirements: Requires a 25mm front connector.
Visit 6ES7521-1BH50-0AA0 for more detail info
For more our products visit turll
