Siemens 6GK1901-1BB11-2AA0 Industrial Ethernet FastConnect RJ45 Plug 180 (4×2) Original Brand New
$21.45
Industrial Ethernet FastConnect RJ45 Plug 180 (4×2) for Gigabit speeds (10/100/1000 Mbit/s). Featuring a rugged metal enclosure and 180° cable outlet, the Siemens 6GK1901-1BB11-2AA0 is optimized for IE FC TP 4×2 cables (AWG24). Reliable, field-assemblable connector for industrial automation.
Availability: In stock
Overview
The Siemens 6GK1901-1BB11-2AA0 is a high-performance Industrial Ethernet FastConnect RJ45 plug designed for demanding networking environments. Featuring a rugged metal enclosure and a 180° cable outlet, this connector supports data transfer rates of 10/100/1000 Mbit/s. It is specifically engineered for use with IE FC TP 4×2 cables (AWG24), ensuring reliable Gigabit Ethernet connectivity in industrial automation settings.
Key Benefit
-
Time-Saving Installation: The FastConnect (FC) system minimizes assembly time by allowing for direct insulation displacement termination.
-
Rugged Durability: The high-quality metal housing provides excellent EMC shielding and physical protection in harsh industrial zones.
-
High-Speed Performance: Fully supports Gigabit Ethernet (1000 Mbit/s) for data-intensive automation tasks.
-
Error-Free Wiring: Integrated color-coding prevents connection errors during field assembly.
Function & Technical Specification
-
Transmission Rate: 10/100/1000 Mbit/s (Gigabit-ready).
-
Cable Outlet: 180° straight outlet for streamlined cable management.
-
Connection Type: Integrated IDC (Insulation Displacement Contact) for IE FC TP 4×2 cables (AWG24).
-
Enclosure Material: Robust metal for industrial-grade interference resistance.
-
Compatibility: Designed for SIMATIC NET and general Industrial Ethernet infrastructures.
Visit 6GK1901-1BB11-2AA0 for more detail info
For more our products visit turll
Download
| Weight | 0.035 kg |
|---|---|
| Dimensions | 55 × 13.7 × 16 mm |
| Product Condition | Brand New, New – Backlog, New – No Original Box, New – Original Box Opened, Used – Average, Used – Below Average, Used – Excellent, Used – Fairly Good, Used – Good, Used – Poor, Used – Very Good |
