High-performance Industrial Ethernet FastConnect RJ45 plug designed for demanding environments. Featuring a rugged metal enclosure and CAT6A compatibility, it supports data transfer rates up to 10 Gbit/s. Its 180° cable outlet and FC connection system ensure easy, error-free installation for IE FC TP 4×2 (AWG24) cables.
Backorder available · Factory lead time 2–3 weeks.
The Siemens 6GK1901-1BB12-2AA0 sets the standard for industrial networking connectivity. Part of the SIMATIC NET family, this Industrial Ethernet FastConnect RJ45 Plug 180 is engineered for high-speed data transmission in automated environments. With its CAT6A rating, it is fully capable of handling 10/100/1000/10000 Mbit/s speeds, providing a future-proof solution for industrial IoT and high-bandwidth applications.
High-Speed Performance: Full CAT6A support ensures reliable 10 Gigabit Ethernet connectivity.
Ruggedized Design: The durable metal housing provides excellent EMC shielding and mechanical stability for harsh industrial floors.
FastConnect (FC) Technology: Significantly reduces assembly time and minimizes wiring errors with the specialized FC connection system.
Tool-Free Installation: Designed for quick field assembly without the need for complex crimping tools.
Space-Efficient: The 180° straight cable outlet is ideal for neat cable management in control cabinets.
Data Transmission: Facilitates high-speed communication between PLC systems, HMIs, and industrial switches.
Direct Connection: Specifically designed for the IE FC TP Cable 4x2 (AWG24).
Environmental Protection: Built to withstand the vibration and electrical noise common in industrial settings.
Transfer Rate: 10 Mbit/s to 10,000 Mbit/s (CAT6A)
Cable Outlet: 180° (Straight)
Enclosure Material: Rugged Metal
Connection System: FastConnect (Insulation displacement)
Compatible Cable: IE FC TP Cable 4x2 (AWG24)
Visit 6GK1901-1BB12-2AA0 for more detail info
For more our products visit turll
| SKU / Model | 6GK1901-1BB12-2AA0 |
|---|---|
| Product Condition | Brand New, New - Backlog, New - No Original Box, New - Original Box Opened, Used - Average, Used - Below Average, Used - Excellent, Used - Fairly Good, Used - Good, Used - Poor, Used - Very Good |
| Weight | 0.035 kg |
| Dimensions | 55 × 13.7 × 16 mm |
