Siemens 6SL3210-1PB13-0AL0 SINAMICS PM240-2 Power Module, 0.37kW – 0.55kW, IP20 Original Brand New

Overview

The Siemens SINAMICS Power Module PM240-2 (6SL3210-1PB13-0AL0) is a high-performance drive module designed for reliable and efficient motor control in industrial automation applications. It features an integrated Class A line filter and integrated braking chopper, reducing installation complexity and ensuring compliance with EMC standards.

Operating on 200–240 V AC (1/3AC) with a frequency range of 47–63 Hz, this power module supports both high overload and low overload applications. Its compact FSA frame size and IP20 protection rating make it ideal for control cabinet installations where space efficiency and performance are critical.

Benefit

• Integrated Safety & Filtering: Comes with a built-in Class A radio interference suppression filter and an integrated braking chopper, reducing the need for external components.

• Dual Overload Capabilities: Optimized for both "High Overload" (HO) for demanding cycles and "Low Overload" (LO) for continuous torque applications.

• Space-Efficient Design: The compact Frame Size A (FSA) housing ensures a small footprint within control cabinets.

• Operational Flexibility: Wide ambient temperature tolerance, operating effectively from -10 °C up to +50 °C depending on load.

Technical Function

• Power Output (LO): 0.55kW (110% overload for 57s).

• Power Output (HO): 0.37kW (200% overload for 3s).

• Input Voltage: 1/3AC 200 V ... 240 V (+10% / -10%).

• Protection Rating: IP20 (Requires installation in a control cabinet).

• Dimensions: 196mm x 73mm x 165mm (H x W x D).

Application

• Industrial automation systems

• Conveyor systems

• Pumps and fans

• Packaging machinery

• Material handling equipment

• General motion control applications

Visit 6SL3210-1PB13-0AL0 for more detail info

For more our products visit turll

Download

Datasheet in PDF
