Siemens 6SL3210-1PE21-1UL0 SINAMICS PM240-2 Power Module, 3kW/4kW, 3AC 380-480V, IP20 Original Brand New

Overview

The Siemens SINAMICS PM240-2 Power Module (6SL3210-1PE21-1UL0) is a high-performance industrial drive module designed for demanding motor control applications. Engineered for reliability and flexibility, this power module features a built-in braking chopper, supports high and low overload conditions, and operates efficiently across a wide temperature range.

This unit is supplied without filter, control unit, or panel, making it ideal for customized automation systems. It is fully approved for Control Unit firmware version V4.6, ensuring seamless integration into SINAMICS drive systems.

Function

• Converts and regulates AC input power for precise motor speed and torque control

• Supports high dynamic load changes with excellent overload handling

• Enables safe braking via integrated braking chopper

• Designed for modular SINAMICS drive configurations

Benefit

• High overload capability for demanding industrial applications

• Built-in braking chopper reduces external component requirements

• Wide voltage and frequency range for global compatibility

• Compact design saves panel space

• Reliable Siemens engineering ensures long service life

• Flexible integration with SINAMICS control units

Technical Specification

• Input Voltage: 3AC 380–480V ±10%

• Frequency: 47–63 Hz

• High Overload Output:

  • 3 kW @ 200% (3 s)

  • 150% (57 s)

  • 100% (240 s)

  • Ambient Temp: -10°C to +50°C

• Low Overload Output:

  • 4 kW @ 150% (3 s)

  • 110% (57 s)

  • 100% (240 s)

  • Ambient Temp: -10°C to +40°C

• Protection Class: IP20

• Frame Size: FSB

• Dimensions (H × W × D): 291 × 100 × 165 mm

• Filter: Without filter

• Control Unit: Not included

• Firmware Compatibility: CU Firmware Version V4.6

Visit 6SL3210-1PE21-1UL0 for more detail info

For more our products visit turll

Download

Datasheet in PDF
