Siemens 3RM1201-1AA04 Reversing Starter, 3RM1 Series, 500V, 0-0.12kW, 24V DC Original Brand New

Model / SKU3RM1201-1AA04

Reversing starter (3RM1 series) supports small motors up to 0.12 kW, 500V, 0.1–0.5A, with 24V DC control and screw terminals for reliable industrial motor control.

Original price was: $396.41.Current price is: $165.74.
In stockShips in 1–3 business days
  • ConditionOriginal Brand New
  • Warranty12 months
Request bulk quoteAsk on WhatsApp
  • Genuine Products
  • Up to 1-Year Warranty
  • Global Shipping
  • Secure Payment
  • PI / Bank Transfer Available
  • Bulk Quote Support

Description

Overview

The Siemens 3RM1201-1AA04 is a high-performance reversing starter from the 3RM1 series, designed for compact and reliable motor control. Engineered to handle voltages up to 500V and currents from 0.1 to 0.5A, this reversing starter ensures precise motor operation with maximum safety. Ideal for small motors ranging from 0 to 0.12 kW, it features durable screw terminals and a robust design for long-lasting performance.

Benefit

  • Space Savings: With a minimal width of just 22.5 mm, it drastically reduces the required footprint in the control cabinet (up to 82% compared to conventional starter combinations).

  • Hybrid Switching Technology: Combines the best of both worlds: low-wear semiconductor technology for making and breaking, and energy-efficient relay technology for continuous operation, leading to significantly longer service life and reduced heat losses.

  • Integrated Overload Protection: Comes standard with an adjustable electronic overload relay (0.1 - 0.5 A), eliminating the need for a separate thermal overload relay and simplifying wiring.

  • Simplified Installation: Features reliable screw terminals for secure and straightforward wiring of the main and control circuits.

  • High Functional Density: Combines reversing functionality, direct starting, and motor protection in one compact housing.

  • Fast Diagnostics: Integrated LED status indicators allow for quick and accurate troubleshooting and error diagnosis.

  • Wide Application Range: Ideal for controlling auxiliary drives such as pumps, fans, and hoisting equipment in various industrial machines and conveyor systems.

Functions & Features

  • Reversing starter for small motors (0–0.12 kW)

  • Voltage rating: 500 V

  • Current range: 0.1–0.5 A

  • Control voltage: 24 V DC

  • Connection type: Screw terminals

  • Compact 3RM1 series design for easy installation

  • Ensures reliable forward and reverse motor operation

  • High safety standards for industrial use

Download

Datasheet in PDF

Visit 3RM1201-1AA04 for more detail info

For more our products visit turll



Specifications

SKU / Model3RM1201-1AA04
BrandSIEMENS
product brand nameSIRIUS
product categoryMotor starter
product designationReversing starter
design of the productwith electronic overload protection
product type designation3RM1
trip classCLASS 10A
equipment variant acc. to IEC 60947-4-23
● intrinsic device protectionYes
● for power supply reverse polarity protectionNo
suitability for operation device connector 3ZY12Yes
power loss [W] for rated value of the current at AC in hot operating state per pole0.01 W
insulation voltage rated value500 V
overvoltage categoryIII
surge voltage resistance rated value6 kV
maximum permissible voltage for safe isolation-
● between main and auxiliary circuit500 V
● between control and auxiliary circuit250 V
shock resistance6g / 11 ms
vibration resistance1 ... 6 Hz, 15 mm; 20 m/s², 500 Hz
operating frequency maximum1 1/s
mechanical service life (switching cycles) typical30 000 000
reference code acc. to IEC 81346-2Q
product function-
● direct startNo
● reverse startingYes
product function short circuit protectionNo
EMC emitted interference acc. to IEC 60947-1class A
EMC immunity acc. to IEC 60947-1Class A
conducted interference-
● due to burst acc. to IEC 61000-4-43 kV / 5 kHz
● due to conductor-earth surge acc. to IEC 61000-4-52 kV
● due to conductor-conductor surge acc. to IEC 61000-4-51 kV
● due to high-frequency radiation acc. to IEC 61000-4-610 V
field-based interference acc. to IEC 61000-4-310 V/m
electrostatic discharge acc. to IEC 61000-4-24 kV contact discharge / 8 kV air discharge
conducted HF interference emissions acc. to CISPR11Class B for the domestic, business and commercial environments
field-bound HF interference emission acc. to CISPR11Class B for the domestic, business and commercial environments
protection class IP on the front acc. to IEC 60529IP20
touch protection on the front acc. to IEC 60529finger-safe
number of poles for main current circuit3
design of the switching contactHybrid
design of the switching contact as NO contact for signaling functionOUT, electronic, 24 V DC, 15 mA
adjustable current response value current of the current-dependent overload release0.1 ... 0.5 A
minimum load [%]20 %; from set rated current
type of the motor protectionsolid-state
operating voltage rated value48 ... 500 V
relative symmetrical tolerance of the operating voltage10 %
operating frequency 1 rated value50 Hz
operating frequency 2 rated value60 Hz
relative symmetrical tolerance of the operating frequency10 %
● at AC at 400 V rated value0.5 A
● at AC-3 at 400 V rated value0.5 A
● at AC-53a at 400 V at ambient temperature 40 °C rated value0.5 A
ampacity when starting maximum4 A
operating power for 3-phase motors at 400 V at 50 Hz0 ... 0.12 kW
input voltage at digital input-
● at DC rated value24 V
input current at digital input-
● for signal <1> at DC11 mA
● with signal <0> at DC1 mA
number of CO contacts for auxiliary contacts1
operational current of auxiliary contacts at AC-15 at 230 V maximum3 A
operational current of auxiliary contacts at DC-13 at 24 V maximum1 A
type of voltage of the control supply voltageDC
control supply voltage at DC rated value19.2 ... 30 V
relative negative tolerance of the control supply voltage at DC20 %
relative positive tolerance of the control supply voltage at DC25 %
control supply voltage 1 at DC rated value24 V
operating range factor control supply voltage rated value at DC-
● initial value0.8
● full-scale value1.25
control current at DC-
● in standby mode of operation25 mA
● when switching on150 mA
duration of inrush current peak at 24 V85 ms
power loss [W] in auxiliary and control circuit-
● in switching state OFF-
● in switching state ON-
— with bypass circuit1.68 W
ON-delay time60 ... 90 ms
OFF-delay time60 ... 90 ms
operational current-
● at 40 °C rated value0.5 A
● at 50 °C rated value0.5 A
● at 55 °C rated value0.5 A
● at 60 °C rated value0.5 A
mounting positionvertical, horizontal, standing (observe derating)
fastening methodscrew and snap-on mounting onto 35 mm standard mounting rail
required spacing-
● with side-by-side mounting-
● for grounded parts-
— forwards0 mm
— backwards0 mm
— upwards50 mm
— at the side3.5 mm
— downwards50 mm
installation altitude at height above sea level maximum4 000 m; For derating see manual
ambient temperature-
● during operation-25 ... +60 °C
● during storage-40 ... +70 °C
● during transport-40 ... +70 °C
environmental category during operation acc. to IEC 607213K6 (no ice formation, only occasional condensation), 3C3 (no salt mist), 3S2 (sand must not get into the devices), 3M6
relative humidity during operation10 ... 95 %
air pressure acc. to SN 31205900 ... 1 060 hPa
protocol is supported-
● PROFINET IO protocolNo
● PROFIsafe protocolNo
product function bus communicationNo
protocol is supported AS-Interface protocolNo
type of electrical connectionscrew-type terminals for main circuit, screw-type terminals for control circuit
● for main current circuitscrew-type terminals
● for auxiliary and control circuitscrew-type terminals
wire length for motor unshielded maximum100 m
● at AWG cables for main contacts1x (20 ... 12), 2x (20 ... 14)
connectable conductor cross-section for main contacts-
connectable conductor cross-section for auxiliary contacts-
● solid or stranded0.5 ... 2.5 mm²
● finely stranded with core end processing0.5 ... 2.5 mm²
type of connectable conductor cross-sections-
— solid1x (0,5 ... 2,5 mm²), 2x (1,0 ... 1,5 mm²)
— finely stranded with core end processing1x (0.5 ... 2.5 mm²), 2x (0.5 ... 1 mm²)
● at AWG cables for auxiliary contacts1x (20 ... 14), 2x (18 ... 16)
AWG number as coded connectable conductor cross section-
● for main contacts20 ... 12
● for auxiliary contacts20 ... 14
operating voltage at AC-
● according to UL rated value480 V
● according to CSA rated value400 V
Test CertificatesRailway other
last modified:11/3/2021
Weight0.340 kg
Dimensions36.00 × 109.00 × 167.00 mm
