1FK2104-4AF01-0MB0 SIEMENS Exclusive SIMOTICS S-1FK2 HD Servo Motor Original Brand New
$739.50
Compact SIEMENS SIMOTICS S-1FK2 servo motor with 1.27 Nm torque, IP65 protection, high dynamic response, and integrated absolute encoder for precise industrial automation.
1FK2104-4AF01-0MB0 SIEMENS Exclusive SIMOTICS S-1FK2 HD Servo Motor Original Brand New
The SIEMENS 1FK2104-4AF01-0MB0 SIMOTICS S-1FK2 servo motor is a compact, high-performance synchronous motor engineered for demanding industrial applications. Offering a rated torque of 1.27 Nm and power ratings of 0.4 kW at 3000 rpm (380–480 V) or 0.2 kW at 1500 rpm (200–240 V), this motor provides efficiency, precision, and flexibility for modern automation systems. With its IP65 protection rating, cylindrical shaft (D19x40 mm), and integrated absolute encoder (22-bit + 12-bit multiturn), it ensures dependable performance even in harsh industrial environments.
This motor is equipped with a DRIVE-CLiQ plug (M17) and a compact power connector, making it simple to integrate into existing systems. Designed to deliver high dynamic response, the motor features low inertia for applications requiring rapid acceleration and precise positioning. It is ideally suited for motion control solutions in sectors such as robotics, packaging, assembly, and handling equipment, where reliability and performance are critical.
Overview
The SIMOTICS S-1FK2 family represents a robust and versatile range of synchronous motors optimized for industrial use. With their excellent power density, overload capacity, and compact design, these motors are the preferred choice for a variety of automation tasks. Their streamlined product range simplifies selection while still offering powerful solutions for servo drive applications.
The portfolio also extends with SIMOTICS 1FT2 motors, which provide finer speed gradations, additional torque levels, and broader variation options. This ensures that even highly specialized or demanding automation requirements can be met effectively.
SIMOTICS S-1FK2 High Dynamic and Compact Motors
- High Dynamic: Optimized with low inertia for applications with low moved masses requiring fast response.
- Compact: Balanced for stable and precise control with medium to high load inertia.
Download
Product Code: 1FK2104-4AF01-0MB0
More Siemens products at Turll.com
| Weight | 2.05 kg |
|---|---|
| Dimensions | 452 × 250 × 267 mm |
