1FK2104-4AF10-0SB0 SIEMENS Exclusive SIMOTICS S-1FK2 HD Servo Motor Original Brand New
$658.03
SIEMENS SIMOTICS S-1FK2 HD servo motor with 1.27 Nm torque, 0.4 kW at 3000 rpm, IP64 protection, 22-bit encoder, and DRIVE-CLiQ connectivity.
1FK2104-4AF10-0SB0 SIEMENS Exclusive SIMOTICS S-1FK2 HD Servo Motor Original Brand New
The SIEMENS 1FK2104-4AF10-0SB0 SIMOTICS S-1FK2 High Dynamic servo motor is designed to deliver outstanding performance, compact dimensions, and maximum reliability for industrial automation. With a rated torque of 1.27 Nm and a power rating of 0.4 kW at 3000 rpm (380–480 V) or 0.2 kW at 1500 rpm (200–240 V), this servo motor is engineered to meet the needs of dynamic motion control applications. Equipped with a holding brake, cylindrical shaft (D19x40mm), and IP64 protection, it provides long service life and robust operation in demanding environments.
This version includes an absolute single-turn encoder (22-bit AS22DQC) for precise positioning, along with a DRIVE-CLiQ plug M17 and power connector M17 for easy integration into SINAMICS drive systems. Its optimized design ensures excellent efficiency and versatility, making it suitable for both standard and advanced automation solutions where high accuracy and responsiveness are required.
Overview
The SIMOTICS S-1FK2 family of servomotors combines compact construction with high power density and outstanding overload capability. They are engineered to tackle the core challenges of modern servo drive technology, providing seamless compatibility with the SINAMICS S210 servo drive system. The product range has been designed for easy selection and integration, with options that support diverse industrial requirements.
Within the portfolio, the SIMOTICS S-1FK2 motors are available as High Dynamic versions with low inertia for fast, precise movements, and Compact versions designed for applications requiring medium to high load inertia. This flexibility allows engineers to select the right motor configuration based on the mechanical demands of their system.
Design
The rugged build of the SIMOTICS S-1FK2 includes an integrated holding brake, durable IP64 housing, and finely matched shaft dimensions. The encoder and DRIVE-CLiQ connectivity guarantee accurate feedback and simple commissioning. As part of the broader SIMOTICS portfolio, these motors can be deployed in a wide variety of environments, ensuring stable performance even under challenging operating conditions.
Download
Product Code: 1FK2104-4AF10-0SB0
More Siemens products at Turll.com
| Weight | 2.9 kg |
|---|---|
| Dimensions | 452 × 250 × 267 mm |
