1FK2104-5AF00-2MA0 SIEMENS Exclusive SIMOTICS S-1FK2 HD Servo Motor Original Brand New

1FK2104-5AF00-2MA0 SIEMENS Exclusive SIMOTICS S-1FK2 HD Servo Motor Original Brand New

The SIEMENS 1FK2104-5AF00-2MA0 SIMOTICS S-1FK2 High Dynamic servo motor is designed to deliver precision, durability, and powerful performance across diverse automation applications. This synchronous motor offers a rated torque of 2.4 Nm, with 0.75 kW output at 3000 rpm (380–480 V) and 0.375 kW at 1500 rpm (200–240 V). Engineered for versatility, it comes with IP64 protection, ensuring reliable operation even in challenging environments. The cylindrical shaft, sized at 14 x 30 mm, provides robust mechanical stability, while the 22-bit absolute encoder with 12-bit multiturn (AM22DQC) ensures high-resolution positioning feedback for demanding automation tasks.

Connectivity and integration are simplified through the OCC interface and rotatable M17 plug, enabling flexible installation in different configurations. The compact design and high power density make this motor particularly well-suited for machine tools, robotics, material handling, and packaging systems where both precision and responsiveness are essential.

Overview

The SIMOTICS S-1FK2 family represents a new generation of compact synchronous motors designed for superior efficiency and adaptability. These motors combine strong overload capability with a limited yet versatile set of options, simplifying the selection process. As a key component of the SINAMICS S210 servo drive system, they provide scalable solutions that meet the diverse requirements of industrial automation.

For applications requiring more customization, the 1FT2 motor range extends the portfolio by offering finer speed gradations, additional torque levels, and broader configuration options. Together, the 1FK2 and 1FT2 series enable businesses to tackle complex automation challenges with confidence, whether focused on highly dynamic applications or stable, precise motion control.

Download

Data Sheet (PDF)

Product Code: 1FK2104-5AF00-2MA0
