1FK2104-5AF01-1SA0 SIEMENS Exclusive SIMOTICS S-1FK2 HD Servo Motor Original Brand New

1FK2104-5AF01-1SA0 SIEMENS Exclusive SIMOTICS S-1FK2 HD Servo Motor Original Brand New

The SIEMENS 1FK2104-5AF01-1SA0 SIMOTICS S-1FK2 High Dynamic servo motor is a compact, efficient, and reliable solution designed for modern industrial automation. With a rated torque of 2.4 Nm and a power output of 0.75 kW at 3000 rpm when operated at 380–480 V, this motor delivers impressive performance for a wide variety of applications. At lower voltage levels of 200–240 V, it offers 0.375 kW at 1500 rpm, ensuring flexibility across different system requirements. Built to IP65 standards, the servo motor provides robust protection against dust and water, making it highly durable even in challenging environments. A 19x40 mm shaft with a feather key, combined with a single-turn 22-bit absolute encoder (AS22DQC), ensures precision, control accuracy, and dependable performance.

Integration is seamless thanks to the OCC interface and a rotatable M17 plug connection, enabling simplified connectivity and installation. Designed with high power density, strong overload capability, and superior efficiency, the SIMOTICS S-1FK2 family is widely used in robotics, packaging machinery, conveyor systems, and CNC applications requiring exact positioning and fast dynamic response.

Overview

The SIMOTICS S-1FK2 series is engineered to address the fundamental demands of servo drive technology. As the core motor range for the SINAMICS S210 drive system, it ensures reliability, compact design, and efficient energy use. The extended 1FT2 motor series builds on this foundation, offering finer speed ranges, additional torque levels, and more configuration options. Together, these product families allow industrial operators to meet diverse automation challenges with scalable and cost-effective solutions.

Download

Data Sheet (PDF)

Product Code: 1FK2104-5AF01-1SA0
