1FK2104-5AF10-0SA0 SIEMENS Exclusive SIMOTICS S-1FK2 HD Servo Motor Original Brand New
$714.69
SIEMENS SIMOTICS S-1FK2 servo motor, 2.4 Nm torque, 0.75 kW at 3000 rpm, IP64 protection, cylindrical shaft, encoder AS22DQC, OCC interface with rotatable M17 plug.
1FK2104-5AF10-0SA0 SIEMENS Exclusive SIMOTICS S-1FK2 HD Servo Motor Original Brand New
The SIEMENS 1FK2104-5AF10-0SA0 SIMOTICS S-1FK2 High Dynamic servo motor is designed to deliver excellent performance, reliability, and efficiency for advanced automation tasks. With a rated torque of 2.4 Nm and power output of 0.75 kW at 3000 rpm (380–480 V) or 0.375 kW at 1500 rpm (200–240 V), this motor provides strong, consistent operation across multiple voltage ranges. The inclusion of a holding brake, IP64 protection rating, and a cylindrical shaft (19×40 mm) ensures dependable use even in demanding industrial environments.
Equipped with a high-resolution absolute single-turn 22-bit encoder (AS22DQC) and a rotatable OCC interface with M17 plug connector, the motor offers flexibility, precision, and easy integration. This makes it a preferred choice for industries that rely on high-accuracy positioning and dynamic motion control, such as packaging systems, robotics, material handling, and machine tool automation.
Overview
The SIMOTICS S-1FK2 family is known for compact size, outstanding dynamic response, and strong overload capacity. These motors form the core solution for SINAMICS S210 servo drive systems, offering simplified configuration with reliable results. By balancing compact design with powerful performance, they meet a wide spectrum of application needs while ensuring easy selection and integration.
For more advanced requirements, the SIMOTICS 1FT2 motors extend the range with finer speed options, increased torque capabilities, and multiple configurations. This scalability enables engineers to match exact performance requirements across diverse automation setups.
Whether for lightweight, highly dynamic movements or medium-inertia loads requiring stable control, SIMOTICS S-1FK2 motors provide efficiency, accuracy, and long-term reliability.
Download
Product Code: 1FK2104-5AF10-0SA0
More Siemens products at Turll.com
| Weight | 3.7 kg |
|---|---|
| Dimensions | 452 × 250 × 267 mm |
