1FK2104-5AF10-1SA0 SIEMENS Exclusive SIMOTICS S-1FK2 HD Servo Motor Original Brand New

1FK2104-5AF10-1SA0 SIEMENS Exclusive SIMOTICS S-1FK2 HD Servo Motor Original Brand New

The SIEMENS 1FK2104-5AF10-1SA0 SIMOTICS S-1FK2 High Dynamic servo motor is designed to deliver exceptional performance in demanding automation environments. Offering a rated torque of 2.4 Nm and a power output of 0.75 kW at 3000 rpm (380–480 V), or 0.375 kW at 1500 rpm (200–240 V), this versatile synchronous motor provides efficiency, durability, and precision control. With its robust IP64 protection rating, integrated holding brake, and 19×40 mm shaft with feather key, it is engineered for long-lasting operation in industrial settings.

This motor is equipped with a single-turn 22-bit absolute encoder (AS22DQC), ensuring high-resolution feedback for precise motion control. The OCC interface with a rotatable M17 plug adds flexibility and simplifies installation. These design features make the unit a reliable choice for applications requiring accurate positioning, fast dynamics, and stable performance under varying loads.

Overview

The SIMOTICS S-1FK2 motor series combines compact construction with high dynamic response and overload capability, making it ideal for automation tasks such as robotics, machine tools, and packaging machinery. As part of the SINAMICS S210 drive system, the 1FK2 motors form a reliable core for precise and efficient servo drive solutions.

The extended 1FT2 series complements the 1FK2 family by offering additional torque levels, refined speed ranges, and broader application flexibility. Together, they provide scalable solutions to address even the most complex challenges in drive technology, ensuring stable operation in diverse industrial environments.

Download

Data Sheet (PDF)

Product Code: 1FK2104-5AF10-1SA0
