1FK2204-5AK10-0MA0 SIEMENS Exclusive SIMOTICS S-1FK2 CT Servo Motor Original Brand New

1FK2204-5AK10-0MA0 SIEMENS Exclusive SIMOTICS S-1FK2 CT Servo Motor Original Brand New

The SIEMENS SIMOTICS S-1FK2 CT servo motor, with product code 1FK2204-5AK10-0MA0, is an advanced synchronous motor engineered for demanding automation tasks. This high-precision motor delivers rated torque of 2.4 Nm and power performance of up to 0.75 kW, depending on operating voltage and speed. Designed with a degree of protection IP64, integrated holding brake, cylindrical shaft (D19x40 mm), and an AM22DQC absolute encoder, this model ensures robust performance, flexibility, and operational safety in industrial environments.

Built to deliver long-lasting reliability, the S-1FK2 series combines compact dimensions with outstanding dynamic response. Thanks to low inertia, the High Dynamic variants excel in applications where speed and responsiveness are essential, while the Compact versions provide precise control for applications requiring stability and consistent performance with medium to high load inertia. This balance between dynamics and robustness makes the SIMOTICS S-1FK2 servo motors an optimal choice for automation systems across various industries.

The 1FK2 range is streamlined with limited but essential variants, simplifying selection and integration. When paired with SINAMICS S210 drive systems, these motors enable exceptional servo control and energy efficiency. For more specialized requirements, the extended 1FT2 motor portfolio offers additional torque levels and refined speed grades, providing even greater adaptability for complex tasks or challenging environments.

Applications for this motor include machine tools, packaging systems, robotics, and general automation tasks requiring precision, repeatability, and high productivity. By combining performance, reliability, and adaptability, the 1FK2204-5AK10-0MA0 represents an exclusive solution that helps industries achieve efficient and future-ready drive technology.

Overview

The SIMOTICS S-1FK2 series offers high power density, durable construction, and excellent overload capability. With compact design and optimized control features, they are particularly suited for servo drive technology where space, speed, and reliability matter. Together with the SINAMICS S210 system, they form a powerful automation platform.

Download

Data Sheet (PDF)

Product Code: 1FK2204-5AK10-0MA0
