1FK7022-5AK71-1DH5-ZJ03 SIEMENS Exclusive SIMOTICS S-1FK7 Compact Servo Motor Original Brand New

1FK7022-5AK71-1DH5-ZJ03 SIEMENS Exclusive SIMOTICS S-1FK7 Compact Servo Motor Original Brand New

The SIEMENS 1FK7022-5AK71-1DH5-ZJ03 SIMOTICS S-1FK7 Compact servo motor is a high-performance permanent-magnet synchronous motor designed for demanding industrial applications. With a rated torque of 0.85 Nm, 0.38 kW power output at 6000 rpm, and naturally cooled operation, this motor provides reliable performance while maintaining compact dimensions. The motor includes a plain shaft with tolerance N, a high-resolution incremental encoder (2048 pulses per revolution), DRIVE-CLiQ interface, and a holding brake. The motor frame is IMB 5, with a flange rated IP67 and a paint finish of RAL7016 J03. The planetary gearing option with 1 stage (I=5) and feather key ensures precise torque transmission for versatile automation tasks.

Designed for installation in space-constrained environments, the SIMOTICS S-1FK7 offers extremely high power density, enabling universal use in modern machine generations. Its low rotor moment of inertia provides high dynamic response, while the high overload capability ensures reliable operation in demanding conditions. The motor is naturally cooled, dissipating heat efficiently through its surface, which reduces the need for additional cooling systems. Connector orientation can be rotated 270° for flexible cabling during installation.

Overview

The SIMOTICS S‑1FK7 series includes compact synchronous motors adaptable to a wide range of applications. Optional encoders and gearboxes expand the product range, allowing integration into various automation systems. These motors are compatible with the SINAMICS S120 and S220 drive systems, providing precise speed and position control. The design minimizes optimization and commissioning effort while maintaining robust closed-loop control properties for both high and variable load inertia.

Benefits and Applications

• Space-saving installation due to high power density.
• Extremely high dynamic response for rapid and precise operations.
• Reliable control even with high or variable load inertia.
• Minimal commissioning effort and robust performance for industrial tasks.
• Ideal for machine tools, robots, handling systems, and packaging machinery.
• Suitable for applications in wood, glass, ceramics, stone, plastics, textiles, and printing machines.

Product Code: 1FK7022-5AK71-1DH5-ZJ03
