1FK7022-5AK71-1LH5-ZJ33 SIEMENS Exclusive SIMOTICS S-1FK7 Compact Servo Motor Original Brand New

1FK7022-5AK71-1LH5-ZJ33 SIEMENS Exclusive SIMOTICS S-1FK7 Compact Servo Motor Original Brand New

The SIEMENS 1FK7022-5AK71-1LH5-ZJ33 SIMOTICS S-1FK7 Compact servo motor is a high-performance, permanently magnetized synchronous motor engineered for precision and efficiency in modern industrial applications. Delivering 0.85 Nm torque and 0.38 kW nominal power at 6000 rpm, this naturally cooled motor provides reliable and energy-efficient operation.

It features a FRAME SIZE IMB 5 flange (IM V1, IM V3) with a plain shaft (tolerance N), an integrated absolute encoder with 20-bit single-turn and 12-bit multiturn resolution, and a Drive-CLiQ interface (encoder AM20DQ). The motor includes power and signal connectors that can rotate 270°, a holding brake, and a robust IP65 protection rating for the motor body with IP67 on the flange. Painted in RAL7016, it is highly durable and suitable for demanding industrial environments.

This compact servo motor is compatible with the SINAMICS S120/S220 drive systems, enabling high-performance control over speed and position. Its design allows heat to dissipate naturally through the motor surface without requiring external cooling, while the high overload capability ensures consistent performance under variable load conditions. Options for planetary gearing, as in the ALPHA SP+ 2-stage planetary gearbox with I=20, provide flexibility for specialized applications. The motor is suitable for a wide variety of industrial machinery, including machine tools, robots, handling systems, and processing machines for wood, glass, ceramics, stone, plastics, and textiles.

Overview

The SIMOTICS S‑1FK7 series combines compact dimensions with high power density, enabling space-saving installation in state-of-the-art machine generations. Available gearboxes, encoder options, and the expanded product range allow engineers to optimize motor performance for specific applications. High-dynamic variants offer rapid response due to low rotor inertia, while high-inertia versions provide robust control for applications with significant or varying load moments. These motors are designed to minimize commissioning time and simplify integration, offering reliable closed-loop control and precise motion performance.

Benefits and Applications

• Space-saving compact installation with high power density
• Universal suitability for a wide range of industrial applications
• High dynamic response for rapid movement and precise positioning
• Robust control for applications with high or variable load inertia
• Reduced commissioning effort with integrated encoder systems
• Ideal for machine tools, robots, handling systems, packaging, printing, and auxiliary axes

Product Code: 1FK7022-5AK71-1LH5-ZJ33
