1FK7032-2AF21-1PA2 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7032-2AF21-1PA2 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

The SIEMENS 1FK7032-2AF21-1PA2 belongs to the advanced SIMOTICS S-1FK7 motor series, a premium range of compact synchronous motors designed for precise and demanding industrial applications. This exclusive model delivers a rated power of 0.31 kW, with a torque of 1.2 Nm at 3000 rpm. Its naturally cooled design, combined with a robust IP65 housing and IP67 flange protection, ensures reliable operation even in challenging environments. With a 2-pole resolver and DRIVE-CLiQ interface, the motor allows seamless communication and integration within automation systems. The rotatable power connector and shaft with feather key offer flexibility and adaptability for various mechanical configurations.

The 1FK7032-2AF21-1PA2 motor stands out due to its efficient design, high overload capability, and maintenance-friendly features. It is built to support long operating cycles, reduced downtime, and enhanced performance consistency. Without the need for a holding brake, the unit is particularly suitable for applications where continuous smooth operation is prioritized. Its compact frame contributes to space-saving installations, while still delivering exceptional dynamics and control accuracy.

Overview

SIMOTICS S-1FK7 motors are permanent-magnet synchronous motors that combine compact dimensions with versatile performance. Thanks to a broad selection of variants, encoder systems, and gearbox options, they can be tailored to virtually any modern machine requirement. When paired with SINAMICS S120 or S220 drive systems, these motors provide a powerful, fully integrated automation solution.

Benefits

• High power density for space-optimized installations
• Robust design supporting wide industrial usage
• Low rotor inertia for excellent dynamic response
• High inertia variants for stable closed-loop control
• Reduced commissioning effort and simplified integration

Application

• Machine tools and robotic systems
• Packaging, printing, and textile industries
• Wood, glass, ceramics, and stone processing
• Handling systems and auxiliary automation axes

Download

Data Sheet (PDF)

Product Code: 1FK7032-2AF21-1PA2
