1FK7032-2AF21-1PH2 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7032-2AF21-1PH2 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

The SIEMENS 1FK7032-2AF21-1PH2 is a compact and high-quality synchronous motor from the SIMOTICS S-1FK7 series, specifically designed for precise industrial motion control applications. Built with advanced permanent-magnet technology, this motor ensures excellent reliability, stable torque, and long service life, even in demanding environments. With a rated power of 0.31 kW, a torque of 1.2 Nm, and a speed of 3000 rpm, it provides an ideal balance between performance and efficiency. The design includes natural cooling, an IMB 5 flange mounting system, and a rotatable power connector, making integration simple and versatile.

The 1FK7032-2AF21-1PH2 features a smooth shaft with holding brake, a resolver equipped with DRIVE-CLiQ interface, and a protection class of IP65 at the motor body and IP67 at the flange. These elements ensure durability, consistent performance, and adaptability to a wide range of industrial conditions. Its robust mechanical and electrical design makes it a reliable choice for automation systems requiring accuracy and minimal downtime.

Overview

SIMOTICS S-1FK7 motors are known for their compact construction, wide adaptability, and outstanding flexibility. They can be combined seamlessly with SINAMICS S120 or S220 drive systems, forming a powerful and integrated automation solution. Depending on the application, a variety of encoder options are available, providing precise speed and position control. These motors are designed to operate without external cooling, dissipating heat effectively through the housing, while maintaining a high overload capacity.

Benefits

• Compact size with high power density for space-saving installations
• Flexible motor range suitable for universal applications
• Excellent dynamic response thanks to low rotor inertia
• Robust control for variable load conditions with minimal optimization effort

Applications

• Machine tools and robotic systems
• Automation in packaging, plastics, and textile industries
• Processing equipment for wood, glass, ceramics, and stone
• High-precision printing machinery
• Auxiliary axes in advanced motion control systems

Download

Data Sheet (PDF)

Product Code: 1FK7032-2AF21-1PH2
