1FK7032-2AF21-1QA0 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7032-2AF21-1QA0 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

The SIEMENS 1FK7032-2AF21-1QA0 is a compact synchronous motor from the SIMOTICS S-1FK7 series, designed for performance, reliability, and integration into advanced drive systems. This exclusive motor offers a rated power of 0.31 kW, delivering a torque of 1.2 Nm at 3000 rpm. Built with precision and efficiency in mind, it features natural cooling, a flange mounting system, and a rotatable power connector for flexible installation. Equipped with an absolute encoder (AS20DQI) with 20-bit resolution and DRIVE-CLiQ interface, the motor ensures high accuracy in speed and position feedback, making it ideal for applications requiring precision and stability.

Its rugged design with IP64 protection allows operation in demanding environments, while the feather-key shaft ensures reliable mechanical connection. The SIMOTICS S-1FK7 series is widely recognized for compact construction and high dynamic performance, providing outstanding adaptability across different industrial sectors. Combined with SINAMICS S120 or S220 drive systems, the motor forms a powerful and efficient solution that supports a wide range of automation requirements.

Overview

The SIMOTICS S-1FK7 family represents a flexible range of permanent-magnet synchronous motors designed to meet modern machine demands. With various configurations available, the motors can be matched precisely to system needs. Integrated encoder options enhance both speed and position control, and the robust thermal design enables heat dissipation directly through the motor housing, eliminating the need for external cooling systems. High overload capacity further increases operational reliability.

Benefits

• Compact construction with excellent power density for space-saving integration
• Versatile product range for universal industrial applications
• High Dynamic versions with low rotor inertia for rapid acceleration
• High Inertia versions with strong control performance under fluctuating loads
• Reduced commissioning effort and reliable compensation for disturbances

Applications

• Machine tools and robotics
• Handling systems and automation lines
• Wood, glass, ceramics, and stone processing
• Packaging, plastics, and textile industries
• Printing machinery and auxiliary axes

Download

Data Sheet (PDF)

Product Code: 1FK7032-2AF21-1QA0
