1FK7032-2AF21-1UA1 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New
$1,101.90
The SIEMENS 1FK7032-2AF21-1UA1 SIMOTICS S synchronous motor is a compact, high-efficiency servo motor offering 0.31 kW output, 1.2 Nm torque, and 3000 rpm speed. Designed for versatile automation, it integrates seamlessly with SINAMICS drives for reliable performance across robotics, machine tools, and packaging applications.
1FK7032-2AF21-1UA1 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New
The SIEMENS 1FK7032-2AF21-1UA1 is a compact synchronous servo motor from the SIMOTICS S-1FK7 series, engineered to deliver precise performance in industrial automation. Designed with advanced permanent-magnet technology, this motor provides a rated power of 0.31 kW at 300 V DC with a torque of 1.2 Nm and a nominal speed of 3000 rpm. The robust IP65 protection ensures reliable operation in demanding environments, while the naturally cooled design supports continuous duty without external cooling systems. With its lightweight construction and versatile mounting options, the motor is highly adaptable for a wide range of machine applications.
This exclusive SIEMENS servo motor is equipped with a multi-pole resolver, DRIVE-CLiQ interface, and rotatable power connector, ensuring flexible integration into modern drive systems. It features a shaft with feather key and tolerance N, offering precise power transmission without a holding brake. The result is a high-efficiency motor with low maintenance requirements and long service life, making it a cost-effective solution for both standard and high-demand operations.
Overview
The SIMOTICS S-1FK7 family combines compact design, high power density, and outstanding flexibility. These motors can be paired seamlessly with SINAMICS S120 or S220 drive systems, enabling optimized performance in speed and position control applications. The integrated encoder options provide excellent precision and allow customization depending on specific requirements.
Benefits
- Space-saving installation due to compact dimensions and high output power
- Wide product range suitable for universal applications
- High overload capacity for challenging operations
- Available in Compact, High Dynamic, and High Inertia variants
- Easy commissioning with minimal optimization effort
Applications
- Machine tools and auxiliary axes
- Robotics and automated handling systems
- Wood, glass, ceramics, and stone processing
- Packaging, plastics, and textile machinery
- Printing equipment requiring precise motion control
Download
Product Code: 1FK7032-2AF21-1UA1
More Siemens products at Turll.com
| Weight | 2.702 kg |
|---|
