1FK7032-2AK71-1CH1 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New
$1,994.05
The SIEMENS 1FK7032-2AK71-1CH1 SIMOTICS S synchronous motor offers 0.5 kW power, 1.15 Nm torque, and 6000 rpm speed. Compact, reliable, and equipped with an advanced encoder, it is ideal for robotics, packaging, and CNC machinery.
1FK7032-2AK71-1CH1 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New
The SIEMENS 1FK7032-2AK71-1CH1 belongs to the advanced SIMOTICS S-1FK7 series, a family of synchronous motors engineered for precision, durability, and flexibility. With a rated power of 0.5 kW, continuous torque of 1.15 Nm at 100K, and a nominal speed of 6000 rpm, this naturally cooled motor is optimized for efficient performance in demanding industrial environments. Its IMB 5 (IM V1, IM V3) flange design with a smooth shaft and integrated holding brake ensures stability and safety during operation. Equipped with an absolute encoder featuring DRIVE-CLiQ interface, this motor delivers accurate speed and position control for high-precision tasks.
Developed with compact dimensions and robust construction, the SIMOTICS S-1FK7 motor range supports a wide variety of industrial applications. The housing is designed for heat dissipation without external cooling, guaranteeing reliable performance under continuous duty. With IP65 protection, the motor provides resistance against dust and water, making it suitable for harsh environments. Its power connector is rotatable for convenient integration into machinery, while tolerance class N ensures precise operation in line with modern engineering standards.
Overview
SIMOTICS S-1FK7 motors are permanent-magnet synchronous motors known for their versatility and adaptability. They can be combined with SINAMICS S120 or S220 drive systems to form a powerful automation solution. Depending on application requirements, various encoder and gearbox options are available. The motor’s compact size and high overload capacity make it an excellent choice for machine generations that require space-saving installation without compromising performance.
Benefits
- Compact structure with outstanding power density for minimal space usage
- Adaptable for a wide range of industrial purposes
- High dynamic response with low rotor inertia for rapid acceleration
- Robust closed-loop control properties for challenging load conditions
- Reduced commissioning effort with integrated optimization features
Application
- Machine tools and CNC machinery
- Robotics and automated handling systems
- Woodworking, glass, ceramics, and stone processing equipment
- Textile, plastics, and packaging industries
- Printing machines and auxiliary drive axes
Download
Product Code: 1FK7032-2AK71-1CH1
More Siemens products at Turll.com
| Weight | 3 kg |
|---|
