1FK7032-2AK71-1CH1-ZJ17 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New
$4,702.02
The SIEMENS 1FK7032-2AK71-1CH1-ZJ17 SIMOTICS S-1FK7 synchronous motor with integrated planetary gearing delivers 0.5 kW power, high precision, and IP65 protection, making it ideal for demanding industrial applications.
1FK7032-2AK71-1CH1-ZJ17 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New
The SIEMENS 1FK7032-2AK71-1CH1-ZJ17 belongs to the SIMOTICS S-1FK7 series, a proven range of compact synchronous motors engineered for precision, durability, and seamless integration with advanced automation systems. This model delivers a rated power of 0.5 kW with a torque of 1.15 Nm at 6000 rpm, providing smooth performance in demanding environments. Featuring natural cooling and a robust IMB 5 flange design, it ensures reliable operation while maintaining efficiency and longevity. The motor is equipped with an absolute encoder (AM24DQI) that provides both 24-bit single-turn and 12-bit multi-turn resolution via DRIVE-CLiQ interface, enabling accurate feedback for position and speed control. A built-in holding brake and smooth shaft design with tolerance N further enhance safety and stability during operation.
One of the standout features of this unit is the integrated ALPHA SP+ planetary gearbox, specifically the SP 075S-MF2 variant with a two-stage configuration, ratio I=50, and feather key connection. This gearing system combines high torque transmission with low backlash, offering robust performance in applications where precision and reliability are critical. Designed with IP65 protection, the motor resists dust and water ingress, making it suitable for harsh industrial environments where durability is essential.
Overview
The SIMOTICS S-1FK7 family is recognized for its versatility and modular design. These motors are compact, space-saving, and deliver high power density. They can be perfectly adapted to diverse requirements thanks to their wide range of options, encoders, and compatible gear units. Whether used as part of the SINAMICS S120 or S220 drive systems, these motors create a powerful combination that simplifies integration while maximizing performance.
Benefits
- Space-efficient design with exceptionally high power density
- Reliable operation for universal industrial applications
- Dynamic response due to reduced rotor inertia
- Stable closed-loop control for high or varying load demands
- Minimal commissioning overhead thanks to optimized system design
Applications
- Machine tools and automation systems
- Robotics and advanced handling equipment
- Wood, glass, ceramics, and stone processing
- Textile, packaging, and plastic machinery
- Printing equipment and auxiliary axes
Download
Product Code: 1FK7032-2AK71-1CH1-ZJ17
More Siemens products at Turll.com
| Weight | 6.9 kg |
|---|
