1FK7032-2AK71-1QG1-ZJ09 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7032-2AK71-1QG1-ZJ09 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

The SIEMENS 1FK7032-2AK71-1QG1-ZJ09 SIMOTICS S synchronous motor is engineered for applications that demand both compact design and exceptional performance. Offering 0.5 kW of rated power at 6000 rpm with a torque rating of 1.15 Nm, this exclusive motor represents precision, efficiency, and reliability in one solution. Designed with a naturally cooled IMB 5 configuration and featuring a rotatable flange-mounted connector, it ensures flexible installation across different environments.

Its integrated absolute encoder with 20-bit resolution and DRIVE-CLiQ interface provides high accuracy for demanding motion control applications. The unit is supplied with a smooth shaft and a planetary gearbox ALPHA SP+ SP 060S-MF1 with a ratio of 1:10, making it highly versatile for mechanical integration. With an IP65 protection class, this motor ensures durability even in harsh industrial settings.

Overview

The SIMOTICS S-1FK7 series is designed as a compact family of permanent-magnet synchronous motors that can be adapted to a wide variety of applications. These motors deliver a perfect balance of power density, precision, and rugged design, enabling machine builders to respond to ever-increasing requirements of modern automation systems. The wide choice of encoder systems and gear configurations allows users to customize performance parameters while ensuring dependable speed and position control. Thanks to the motor’s overload capability and efficient heat dissipation through its housing, it operates consistently without requiring external cooling systems.

Benefits

• Space-saving design with exceptional power density
• Flexible encoder options and gear integration for diverse applications
• High dynamic response for machines requiring fast acceleration
• Robust performance even under variable load conditions
• Reduced commissioning time and simplified system integration

Application

• Machine tools
• Robotics and automated handling systems
• Packaging, plastics, and textile production
• Printing, woodworking, and material processing
• Auxiliary axes for complex machinery

Download

Data Sheet (PDF)

Product Code: 1FK7032-2AK71-1QG1-ZJ09
