1FK7032-2AK71-1RG0-ZN05 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7032-2AK71-1RG0-ZN05 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

The SIEMENS 1FK7032-2AK71-1RG0-ZN05 belongs to the advanced SIMOTICS S-1FK7 motor series, designed to deliver precision, efficiency, and reliability in modern automation systems. This compact permanent-magnet synchronous motor is rated at 0.5 kW with a continuous torque of 1.15 Nm at 6000 rpm, operating at a DC voltage of 600 V. It features natural cooling, a rotatable flange-mounted power connector, and a smooth shaft compatible with the 1FK503X series. The integrated absolute encoder with DRIVE-CLiQ interface provides 20-bit resolution plus 12-bit multi-turn capability, ensuring outstanding accuracy for demanding positioning applications. With IP64 protection and robust mechanical design, this model guarantees reliable performance in challenging environments.

The motor’s adaptability is one of its strongest advantages. It can be combined with SINAMICS S120 or S220 drive systems to create a high-performance motion control solution. Heat dissipation occurs directly through the motor surface, eliminating the need for external cooling and reducing overall system complexity. This construction allows higher overload capacity, enhancing operational flexibility. Thanks to its compact form factor, it enables space-saving installation even where limited mounting space is available.

Overview

SIMOTICS S-1FK7 motors are engineered for precision motion control across a wide range of industries. With scalable encoder options and mechanical variants, they provide optimal integration into diverse applications. These motors meet the evolving requirements of state-of-the-art machinery, offering smooth performance with minimal maintenance.

Benefits

• Space-efficient installation with high power density
• Available in Compact, High Dynamic, and High Inertia versions
• High overload capability with stable closed-loop control
• Low commissioning effort with integrated encoder systems

Application

• Machine tools
• Robotics and handling equipment
• Wood, glass, ceramics, and stone processing
• Packaging and textile machinery
• Printing and auxiliary axes

Download

Data Sheet (PDF)

Product Code: 1FK7032-2AK71-1RG0-ZN05
