1FK7032-2AK71-1RH1-ZJ02 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7032-2AK71-1RH1-ZJ02 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

The SIEMENS 1FK7032-2AK71-1RH1-ZJ02 SIMOTICS S synchronous motor is a premium industrial solution designed for high-performance motion control. Delivering 0.5 kW power with a torque of 1.15 Nm at a nominal speed of 6000 rpm, this compact motor provides exceptional reliability and adaptability for a wide range of industrial applications. With its natural cooling design, IP65 protection class, and IMB 5 configuration, the motor ensures robust operation even in demanding environments. The integrated absolute encoder with DRIVE-CLiQ interface enhances precision for position and speed control, while the smooth shaft and holding brake guarantee safe and efficient performance.

This exclusive model is equipped with the ALPHA SP+ planetary gear unit (SP 060S-MF1), offering a single-stage transmission with a ratio of i=4, complete with feather key design for secure power transmission. The combination of advanced gearing technology and compact motor design delivers high power density in limited spaces, supporting applications that demand consistent accuracy and dynamic response. The versatility of the motor makes it suitable for integration with the SINAMICS S120/S220 drive system, creating a powerful automation setup with advanced diagnostic and control features.

Overview

SIMOTICS S-1FK7 motors are compact permanent-magnet synchronous motors engineered for flexibility and efficiency. With multiple encoder and gearbox options, they can be customized to fit specific requirements across various industries. Their superior overload capacity and robust mechanical design make them a trusted choice for next-generation machines. Combined with SINAMICS drives, they ensure reliable performance, fast commissioning, and reduced maintenance overhead.

Benefits

• Space-saving installation thanks to high power density
• Wide motor range for universal applications
• High Dynamic series: rapid response due to low rotor inertia
• High Inertia series: stable closed-loop control for varying loads
• Minimal optimization needed for reliable operation

Application

• Machine tools
• Robotics and handling systems
• Wood, glass, ceramics, and stone processing
• Packaging, plastics, and textile machinery
• Printing presses
• Auxiliary axes in automation systems

Download

Data Sheet (PDF)

Product Code: 1FK7032-2AK71-1RH1-ZJ02
