1FK7032-2AK71-1RH1-ZJ12 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7032-2AK71-1RH1-ZJ12 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

The SIEMENS 1FK7032-2AK71-1RH1-ZJ12 SIMOTICS S synchronous motor is a highly reliable and efficient solution designed for demanding automation and motion control applications. Delivering a rated power of 0.5 kW with a nominal torque of 1.15 Nm, this compact motor operates at a nominal speed of 6000 rpm under a DC link voltage of 600V.

The naturally cooled design ensures consistent thermal management, while the IMB 5 mounting configuration with a rotatable power connector allows flexible installation in a variety of machine setups. The motor features a 20-bit absolute encoder combined with a 12-bit multi-turn system, providing precise positioning and accurate feedback through the DRIVE-CLiQ interface. Equipped with a smooth shaft, holding brake, and IP65 protection, this unit is built to perform reliably in industrial environments.

One key highlight of this model is its integration with an ALPHA SP+ planetary gear unit (SP 060S-MF2) featuring two stages and a gear ratio of 16. With a feather key design, this gearing system enhances torque transmission and mechanical efficiency, making the motor suitable for applications where precision and strength must be combined. The motor’s rugged build and advanced encoder technology ensure seamless operation in diverse automation systems.

Overview

SIMOTICS S-1FK7 motors are compact, permanent-magnet synchronous motors that offer exceptional flexibility thanks to a broad selection of options, encoders, and gear units. They can be paired with SINAMICS S120 or S220 drive systems to form a powerful automation package. The compact form factor, natural cooling system, and high overload capability make these motors ideal for advanced machine designs.

Benefits

• Space-efficient design with high power density for modern machinery
• Universal applicability across different industries and automation systems
• High dynamic response with low rotor inertia for fast control performance
• Robust closed-loop control for varying load conditions
• Minimal commissioning effort thanks to optimized disturbance compensation

Applications

• Machine tools
• Robotics and handling systems
• Woodworking, glass, ceramics, and stone machinery
• Packaging, plastic, and textile production equipment
• Printing machines and auxiliary drive systems

Download

Data Sheet (PDF)

Product Code: 1FK7032-2AK71-1RH1-ZJ12
