1FK7033-4CK71-1CB2 SIEMENS Exclusive SIMOTICS S-1FK7 Synchronous Motor Original Brand New

1FK7033-4CK71-1CB2 SIEMENS Exclusive SIMOTICS S-1FK7 Synchronous Motor Original Brand New

The SIEMENS 1FK7033-4CK71-1CB2 is part of the advanced SIMOTICS S-1FK7 family, designed for precise and dynamic performance in modern automation environments. This exclusive synchronous motor delivers a nominal power of 0.57 kW with a torque rating of 1.3 Nm (100K) and operates efficiently at 6000 rpm. Engineered for naturally cooled operation, the motor’s heat dissipation is optimized through its rugged housing, ensuring consistent performance and extended service life even under demanding conditions.

Featuring a 24-bit absolute encoder with an additional 12-bit multi-turn function via the DRIVE-CLiQ interface, this motor offers exceptional accuracy in speed and position feedback. The fitted-key shaft and integrated holding brake enhance mechanical stability and safety, while the rotatable power connector allows for flexible installation within control cabinets or machinery frames. With IP65 protection and an IP67 flange, it withstands dust and moisture, providing reliable operation in industrial settings.

Overview

SIMOTICS S-1FK7 motors are compact permanent-magnet synchronous units built for maximum versatility. These motors combine efficiency, high torque density, and robust design, making them ideal for a wide variety of industrial applications. The 1FK7033-4CK71-1CB2 integrates seamlessly with SINAMICS S120 or S220 drive systems, forming a powerful automation solution with intelligent control features and fast response time.

Benefits & Applications

• Space-saving design with high power-to-size ratio
• Enhanced precision through high-resolution encoder system
• Reduced commissioning effort and minimal maintenance
• Suitable for machine tools, robotic systems, and material-handling equipment
• Excellent choice for packaging, woodworking, glass, ceramics, and textile production
• Reliable performance for auxiliary axes and multi-axis automation setups

Download

Data Sheet (PDF)

Product Code: 1FK7033-4CK71-1CB2
