1FK7033-4CK71-1CG0-ZB02 SIEMENS Exclusive SIMOTICS S-1FK7 Synchronous Motor Original Brand New

1FK7033-4CK71-1CG0-ZB02 SIEMENS Exclusive SIMOTICS S-1FK7 Synchronous Motor Original Brand New

The SIEMENS 1FK7033-4CK71-1CG0-ZB02 SIMOTICS S-1FK7 synchronous motor delivers precision, durability, and high performance in a compact form factor. Engineered for industrial environments, this motor is part of the renowned SIMOTICS S-1FK7 series, designed to meet the evolving demands of modern automation systems. With a power rating of 0.57 kW, torque of 1.3 Nm, and a rated speed of 6000 rpm, this model provides outstanding dynamic behavior and long-term reliability for a wide range of industrial machinery.

This naturally cooled synchronous motor features an IMB 5 (IM V1, IM V3) frame design and a rotatable power connector, enabling flexible installation in confined spaces. It is equipped with a high-resolution 24-bit absolute encoder plus 12-bit multiturn system using the DRIVE-CLiQ interface (AM24DQI), allowing accurate feedback and control when paired with SINAMICS S120 or S220 drive systems. The plain shaft with tolerance N ensures smooth motion transfer, and its IP64 protection rating offers strong resistance to dust and splash water, extending the operational lifespan even under challenging conditions.

Overview

SIMOTICS S-1FK7 motors are compact permanent-magnet synchronous units optimized for versatility and adaptability. With a wide range of power ratings, encoder options, and gear configurations, these motors are suitable for countless automation applications where precision, performance, and reliability are essential. Their high overload capacity and efficient heat dissipation contribute to stable performance even during intensive use.

Benefits & Applications

• Compact design with high power density for space-efficient installation
• High dynamic response due to low rotor inertia
• Versatile integration with SINAMICS drive systems
• Minimal setup time and simplified commissioning
• Ideal for robotics, machine tools, packaging, and textile machinery
• Compliant with EN 10204-2.3 Acceptance Test Certificate (B02)

Download

Data Sheet (PDF)

Product Code: 1FK7033-4CK71-1CG0-ZB02
