1FK7034-2AF21-1BG1-ZJ17X01 SIEMENS Exclusive SIMOTICS S-1FK7 Synchronous Motor Original Brand New
$4,684.54
The SIEMENS 1FK7034-2AF21-1BG1-ZJ17X01 SIMOTICS S-1FK7 motor combines compact size, precision control, and integrated planetary gearing for advanced automation performance. Built for durability and accuracy, it’s ideal for demanding industrial applications.
1FK7034-2AF21-1BG1-ZJ17X01 SIEMENS Exclusive SIMOTICS S-1FK7 Synchronous Motor Original Brand New
The SIEMENS 1FK7034-2AF21-1BG1-ZJ17X01 SIMOTICS S-1FK7 synchronous motor is an advanced, high-precision drive solution designed to meet the demanding requirements of modern automation and motion control systems. This permanent-magnet synchronous motor delivers a nominal power of 0.47 kW with a torque of 1.6 Nm at 3000 rpm, offering efficient and smooth operation across industrial applications. With its compact IMB 5 design and natural cooling system, it provides reliable performance without the need for external cooling equipment. The rotatable power connector enhances installation flexibility, while the smooth shaft with tolerance N ensures accurate mechanical connection.
Equipped with a 24-bit single-turn absolute encoder using the DRIVE-CLiQ interface (AS24DQI), this motor ensures precise feedback for accurate position and speed control. The model includes an integrated planetary gear unit, the ALPHA SP+ 100S-MF2 with a two-stage reduction ratio of 50:1, designed to deliver high torque transmission efficiency and low backlash. The dull black RAL9005 paint finish enhances durability and corrosion resistance, making it suitable for various industrial environments.
Overview
The SIMOTICS S-1FK7 motor range offers versatile performance across different industrial sectors. These motors can be combined with SINAMICS S120 or S220 drive systems to create highly functional motion control setups. Depending on the application, users can select from a variety of encoder systems and mechanical configurations to achieve the desired performance and responsiveness.
Benefits & Applications
- Compact size and high power density for space-saving installations
- Exceptional control precision and dynamic performance
- Integrated planetary gearbox for smooth torque transmission
- Low maintenance with IP65 protection for harsh industrial environments
- Ideal for machine tools, robotic systems, packaging, and handling machinery
- Durable black finish for enhanced corrosion resistance
Download
Product Code: 1FK7034-2AF21-1BG1-ZJ17X01
More Siemens products at Turll.com
| Weight | 7.602 kg |
|---|
