1FK7034-2AF21-1FG2 SIEMENS Exclusive SIMOTICS S-1FK7 Synchronous Motor Original Brand New

1FK7034-2AF21-1FG2 SIEMENS Exclusive SIMOTICS S-1FK7 Synchronous Motor Original Brand New

The SIEMENS 1FK7034-2AF21-1FG2 SIMOTICS S-1FK7 synchronous motor is a high-quality, precision-engineered solution designed for demanding automation environments. It combines performance, efficiency, and reliability in a compact design, offering a nominal power of 0.47 kW and a torque of 1.6 Nm at 3000 rpm. Operating with a 300V DC supply, the motor’s naturally cooled construction enables effective heat dissipation through its robust surface, ensuring consistent performance without external cooling systems.

This exclusive synchronous motor features a 22-bit absolute encoder with an additional 12-bit multi-turn system using the DRIVE-CLiQ interface (encoder AM22DQ), providing exceptional accuracy for speed and position feedback. The smooth shaft design, with standard tolerance N and without a holding brake, ensures mechanical stability and low maintenance. Its IP65 protection rating, and IP67 protection on the drive end flange, guarantees long-lasting performance in tough industrial conditions. The rotatable power connector further enhances installation flexibility, making this motor adaptable for different machine layouts.

Overview

SIMOTICS S-1FK7 motors are compact permanent-magnet synchronous motors optimized for modern automation systems. They can be paired with SINAMICS S120 or S220 drive systems to create a high-performance motion solution with integrated control and feedback functions. The modular product range, with multiple frame sizes and encoder types, allows for precise customization based on application requirements.

Benefits & Applications

• Compact, space-saving design with high power density
• Excellent overload capacity for dynamic applications
• Wide range of options for mechanical and electrical integration
• Precise position and speed control with integrated encoder technology
• Ideal for machine tools, robotics, and material handling systems
• Perfect for packaging, plastics, textile, and printing machinery

Download

Data Sheet (PDF)

Product Code: 1FK7034-2AF21-1FG2
