1FK7034-2AK71-1CH0-ZV42 SIEMENS Exclusive SIMOTICS S-1FK7 Synchronous Motor Original Brand New
$3,002.86
The SIEMENS 1FK7034-2AK71-1CH0-ZV42 SIMOTICS S-1FK7 motor is a compact, high-precision synchronous motor featuring an integrated 10:1 planetary gear, encoder feedback, and IP64 protection, ideal for advanced industrial automation.
1FK7034-2AK71-1CH0-ZV42 SIEMENS Exclusive SIMOTICS S-1FK7 Synchronous Motor Original Brand New
The SIEMENS 1FK7034-2AK71-1CH0-ZV42 SIMOTICS S-1FK7 synchronous motor is a high-precision, compact drive solution engineered for advanced automation systems. This permanent-magnet motor delivers a nominal power of 0.63 kW and torque of 1.6 Nm at a speed of 6000 rpm. The naturally cooled IMB 5 design, featuring a rotatable power connector and smooth shaft, ensures efficient operation in confined spaces and demanding industrial settings. With IP64 protection, it provides excellent resistance against dust and moisture, guaranteeing consistent performance and long service life.
Equipped with a 24-bit absolute encoder plus a 12-bit multi-turn system via the Drive-CLiQ interface, this model offers outstanding speed and position feedback accuracy. The built-in holding brake enhances operational safety, while the integrated planetary gearing (ALPHA LP+, LP 070-MO1) with a 1-stage ratio of 10:1 provides optimized torque transmission and mechanical precision. This configuration is ideal for machinery requiring accurate motion control and repeatable positioning.
Overview
SIMOTICS S-1FK7 motors are known for their flexibility, compact size, and high performance. They can be easily combined with SINAMICS S120 or S220 drive systems to create a complete motion control solution. With options for different encoders, gearboxes, and inertia classes, these motors can be tailored to diverse industrial applications, from light-duty automation to high-torque operations.
Benefits & Applications
- Compact design with high power density for space-efficient installations
- Exceptional precision with integrated multi-turn encoder and Drive-CLiQ connectivity
- Integrated planetary gearbox ensures superior torque and speed control
- High overload capacity and stable operation without external cooling
- Ideal for machine tools, robotic systems, packaging, and printing equipment
- Applicable to plastics, textiles, wood, and glass processing industries
Download
Product Code: 1FK7034-2AK71-1CH0-ZV42
More Siemens products at Turll.com
| Weight | 5.9 kg |
|---|
