1FK7034-2AK71-1UG1-ZJ09 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7034-2AK71-1UG1-ZJ09 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

The SIEMENS SIMOTICS S 1FK7034-2AK71-1UG1-ZJ09 is a high-quality synchronous motor designed to deliver precise, efficient, and durable performance in modern industrial environments. Built with advanced technology and a compact configuration, this motor ensures optimal power output and seamless integration within a wide variety of automation systems.

Featuring a rated power of 0.63 kW and a rated torque of 1.6 Nm at 6000 rpm, it provides stable operation with natural cooling and superior mechanical balance. The integrated multi-pole resolver with DRIVE-CLiQ interface ensures accurate communication and control when combined with SIEMENS drive systems. With IP65 protection, a smooth shaft, and a flange-mounted IMB 5 design, this motor is engineered for reliability in demanding conditions. The ALPHA SP+ planetary gearing (SP 060S-MF1, 1 stage, I=10) further enhances torque transmission efficiency and smooth operation.

Overview

The SIMOTICS S-1FK7 series represents the next generation of compact permanent-magnet synchronous motors from SIEMENS. These motors are designed for flexibility and scalability across a wide range of industrial applications. With options for various encoders, gearboxes, and mechanical designs, they adapt easily to specific machine configurations. When integrated with SINAMICS S120 or S220 drive systems, they form a highly responsive, feature-rich automation solution capable of precise speed and position control. Heat dissipation occurs naturally through the motor surface, supporting maintenance-free operation and enhanced energy efficiency. The design achieves a high overload capacity, ensuring consistent output even during heavy-duty operations.

Benefits

• Compact structure with extremely high power density for space-saving installation
• Flexible use across numerous industrial applications
• Available in multiple torque and speed variants
• High dynamic response due to low rotor inertia
• Excellent closed-loop control for systems with varying load conditions
• Reduced commissioning effort with minimal tuning required

Applications

• Machine tools and automation systems
• Robotic and handling units
• Wood, glass, ceramics, and stone processing equipment
• Packaging, plastics, and textile machinery
• Printing and auxiliary drive systems

Download

Data Sheet (PDF)

Product Code: 1FK7034-2AK71-1UG1-ZJ09
