1FK7042-2AC71-1CG1-ZJ05 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New
$3,648.07
The SIEMENS SIMOTICS S 1FK7042-2AC71-1CG1-ZJ05 is a compact synchronous motor designed for superior accuracy, torque efficiency, and smooth operation. Featuring a 3 Nm rated torque, 2000 rpm speed, and integrated ALPHA SP+ planetary gearing, it offers high performance, low maintenance, and precise control in industrial automation systems.
1FK7042-2AC71-1CG1-ZJ05 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New
The SIEMENS SIMOTICS S 1FK7042-2AC71-1CG1-ZJ05 is a premium synchronous servo motor engineered for exceptional performance, precision, and reliability in demanding industrial environments. Designed as part of the renowned SIMOTICS S-1FK7 series, this compact motor delivers 0.59 kW nominal power with a rated torque of 3 Nm at 2000 rpm. Operating at 600V DC, it combines natural cooling, smooth shaft, and IP65 protection for durability even in harsh operating conditions. The model integrates a high-resolution 24-bit + 12-bit multi-turn absolute encoder (Drive-CLiQ interface) for accurate speed and position feedback, ensuring consistent performance across a wide range of automation systems.
Overview
The SIMOTICS S-1FK7 motor family represents a new generation of permanent-magnet synchronous motors, developed to meet the growing demands of advanced industrial automation. These motors can be seamlessly integrated with SINAMICS S120/S220 drive systems, creating a flexible, high-performance motion control solution. The combination provides outstanding functionality and easy adaptation to various applications through multiple encoder and gearbox configurations. The 1FK7042-2AC71-1CG1-ZJ05 variant includes an ALPHA SP+ planetary gearing (SP 075S-MF1, 1-stage, i=7) with a feather key, enhancing torque delivery and energy efficiency. The motor’s natural convection cooling design allows operation without external fans, simplifying maintenance while ensuring excellent thermal management.
Benefits
- Compact dimensions with high power density for space-optimized installations
- Universal application range across multiple industrial sectors
- Flexible integration with Siemens drive systems for customized performance
- High overload capacity for reliable continuous operation
- Available in Compact, High Dynamic, and High Inertia variants for versatile motion control
- Accurate feedback through integrated encoder systems for precise motion accuracy
Applications
The 1FK7042-2AC71-1CG1-ZJ05 motor is ideal for applications requiring high dynamics and precision, including machine tools, robotics, packaging lines, and materials processing equipment. It performs exceptionally well in sectors such as woodworking, glass, ceramics, textiles, and printing, where consistent motion control and compact motor design are crucial. Its robust structure and modular adaptability make it a perfect choice for both auxiliary axes and main motion systems within automation setups.
Download
Product Code: 1FK7042-2AC71-1CG1-ZJ05
More Siemens products at Turll.com
| Weight | 8.201 kg |
|---|
