1FK7042-2AF24-1SH2 SIEMENS Exclusive SIMOTICS S-1FK7 Compact Synchronous Motor Original Brand New

1FK7042-2AF24-1SH2 SIEMENS Exclusive SIMOTICS S-1FK7 Compact Synchronous Motor Original Brand New

The SIEMENS SIMOTICS S-1FK7 synchronous motor with part number 1FK7042-2AF24-1SH2 is a high-performance, compact permanent-magnet motor engineered for demanding industrial applications. Delivering 0.82 kW of continuous power at 300 V, it features a 3 Nm torque rating and a maximum speed of 3000 rpm. Its naturally cooled design with IP65 protection ensures reliable operation even under challenging environmental conditions, while the DE flange with IP67 rating provides additional protection for the drive connection. The motor incorporates a Pt1000 temperature sensor for accurate thermal monitoring, a smooth shaft with tolerance N, and a multi-pole resolver for precise position feedback. The integrated holding brake further enhances operational safety and stability.

Overview

The SIMOTICS S-1FK7 motors are highly versatile and can be adapted to various industrial requirements thanks to a wide range of available options, including gearboxes and encoders. Combining these motors with the SINAMICS S120 or S220 drive system creates a robust and high-performance solution with exceptional functionality. Integrated encoder systems allow precise speed and position control tailored to the specific application. Designed for operation without external cooling, these motors dissipate heat efficiently through the surface, providing a compact yet powerful solution for high-demand environments. Their high overload capacity ensures they maintain performance during temporary peak loads.

Benefits

SIMOTICS S-1FK7 Compact motors save valuable installation space due to their high power density and can be applied universally across different machine types. High Dynamic variants provide extremely fast response times thanks to low rotor inertia, ideal for applications requiring rapid acceleration or deceleration. High Inertia models deliver robust closed-loop control even under high or variable load moments. Minimal commissioning and optimization requirements reduce setup time and simplify maintenance, allowing rapid deployment in production systems.

Applications

This motor series is ideally suited for machine tools, robots, and handling systems. It also supports applications in woodworking, glass, ceramics, stone, packaging, plastics, textile machinery, printing equipment, and auxiliary axes, offering flexibility for a broad spectrum of industrial automation challenges.

Product Code: 1FK7042-2AF24-1SH2
