1FK7042-2AF71-1CG1-ZX01 SIEMENS Exclusive SIMOTICS S-1FK7 Synchronous Motor Original Brand New

1FK7042-2AF71-1CG1-ZX01 SIEMENS Exclusive SIMOTICS S-1FK7 Synchronous Motor Original Brand New

The SIEMENS 1FK7042-2AF71-1CG1-ZX01 belongs to the SIMOTICS S-1FK7 family of compact synchronous servo motors, renowned for their precision, durability, and outstanding performance in demanding automation environments. Designed for universal motion applications, this motor delivers 0.82 kW rated power at a nominal speed of 3000 rpm and provides a continuous torque of 3 Nm (100 K). With a rated DC link voltage of 600 V and natural cooling (IMB 5 / IM V1 / IM V3 flange 1 mounting), it ensures stable and efficient operation even under variable loads. The unit includes an AM24DQI absolute encoder system with 24-bit + 12-bit multiturn resolution using the DRIVE-CLiQ interface, ensuring precise feedback and synchronization with SINAMICS S120 or S220 servo drives.

Overview

The SIMOTICS S-1FK7 motor series is a trusted solution for advanced automation systems requiring dynamic motion control. Each motor is built with high-grade permanent magnets and optimized rotor geometry to achieve exceptional responsiveness with minimal inertia. These motors operate efficiently without external cooling, dissipating heat through the housing for long-term reliability. The design supports fast acceleration, high repeat accuracy, and robust operation across various mechanical configurations. Combining a SIMOTICS S-1FK7 motor with SINAMICS drive systems creates a high-performance mechatronic unit ideal for both precision and endurance.

Benefits

The compact version provides space-saving installation with excellent power density, making it ideal for machine builders who need flexibility and precision in limited spaces. The high dynamic variant offers ultra-fast response due to its lightweight rotor, while the high inertia models provide stable, controlled torque under variable or heavy loads. Each motor is manufactured with durable components for long service life and minimal maintenance.

Applications

The 1FK7042-2AF71-1CG1-ZX01 is widely applied in machine tools, robotics, packaging systems, printing equipment, and textile or glass processing lines. Its versatile configuration allows engineers to integrate it seamlessly into both new and retrofit automation solutions, achieving precise motion, repeatable accuracy, and energy-efficient operation.

Download

Data Sheet (PDF)

Product Code: 1FK7042-2AF71-1CG1-ZX01
