1FK7042-2AF71-1CH0 SIEMENS Exclusive SIMOTICS S-1FK7 Synchronous Motor Original Brand New

1FK7042-2AF71-1CH0 SIEMENS Exclusive SIMOTICS S-1FK7 Synchronous Motor Original Brand New

The SIEMENS SIMOTICS S-1FK7 synchronous motor with part number 1FK7042-2AF71-1CH0 is a highly reliable, compact permanent-magnet motor engineered for advanced industrial applications. Delivering 0.82 kW of power at 3000 rpm, this motor operates at 600 V DC and provides a torque of 3 Nm, making it suitable for precision tasks in modern automation systems. The motor is naturally cooled, robustly built with an IP64 protection rating, and equipped with a plain shaft with tolerance N for secure mechanical integration.

Overview

The SIMOTICS S‑1FK7 series represents Siemens’ high-performance line of compact synchronous motors. Designed for universal industrial applications, these motors are versatile and can be perfectly paired with gearboxes and encoders depending on specific requirements. With DRIVE-CLiQ interface and an absolute encoder (24-bit + 12-bit multiturn), the system ensures precise speed and position control. They are fully compatible with SINAMICS S120/S220 drive systems to provide powerful, reliable, and highly functional integrated drive solutions.

Benefits

SIMOTICS S‑1FK7 motors combine compact size with high energy efficiency, allowing for space-saving installation and minimal commissioning overhead. The high dynamic models offer extremely fast response times due to their low rotor inertia, while the high inertia variants provide robust closed-loop control under high or variable load conditions. The motors’ intelligent design allows for efficient heat dissipation through the surface, eliminating the need for external cooling and enhancing reliability in continuous operation.

Applications

These motors are ideal for a wide range of industrial machinery including machine tools, robots, handling systems, and auxiliary axes. They also suit processing machines for wood, glass, ceramics, stone, plastics, and textiles, as well as printing equipment. Thanks to the high overload capability and durable design, the motors maintain performance even in demanding conditions, making them a preferred choice for modern automated manufacturing setups.

Download

Data Sheet (PDF)

Product Code: 1FK7042-2AF71-1CH0
