1FK7042-2AK71-1RB1-ZN16 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7042-2AK71-1RB1-ZN16 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

The SIEMENS SIMOTICS S 1FK7042-2AK71-1RB1-ZN16 is a high-precision synchronous motor engineered for performance, reliability, and exceptional energy efficiency in advanced automation systems. With a rated power of 0.94 kW and a torque of 3 Nm at 6000 rpm, this model provides precise motion control and smooth torque output across demanding industrial applications. The naturally cooled construction (IMB 5) with a rotatable power connector ensures flexible installation, while the IP65 protection rating delivers long-term durability in challenging production environments.

This exclusive motor integrates an absolute encoder AM20DQI featuring 20-bit single-turn and 12-bit multi-turn resolution via a Drive-CLiQ interface. It guarantees exact position feedback, superior synchronization, and minimal vibration even under dynamic load conditions. Its mechanically rugged shaft with a feather key and built-in holding brake provides stable performance and optimized torque transmission. The N16 version offers enhanced chemical resistance with a robust M17 encoder plug, making it suitable for industrial sectors that require resilient operation in harsh or corrosive environments.

Overview

SIMOTICS S 1FK7 motors from SIEMENS are compact, permanent-magnet synchronous motors designed for precision and adaptability. Their modular design allows a wide range of configuration options, including different encoders and gearbox combinations, to perfectly fit diverse automation requirements. When combined with the SINAMICS S120 / S220 drive systems, they form a highly integrated motion solution with advanced functionality for servo-driven applications.

Benefits

• Compact design ensures efficient space utilization and easy integration
• Available in multiple variants for universal and specialized applications
• Exceptional dynamic performance due to low rotor inertia
• Reliable closed-loop control for stable performance under varying loads
• Minimal commissioning time and simplified system optimization

Applications

• Machine tools and precision automation systems
• Robotics and handling equipment
• Wood, glass, ceramics, and stone processing machinery
• Packaging, plastics, and textile industries
• Printing and auxiliary drive systems

Download

Data Sheet (PDF)

Product Code: 1FK7042-2AK71-1RB1-ZN16
