The SIEMENS SIMOTICS S 1FK7044-4CF71-1CH2-ZQ31 synchronous motor delivers 1.2 kW power and 4.5 Nm torque with a 24-bit encoder, DRIVE-CLiQ interface, holding brake, and IP65 protection—ideal for precision automation systems.
The SIEMENS SIMOTICS S 1FK7044-4CF71-1CH2-ZQ31 is a high-performance synchronous motor designed for precision, efficiency, and reliability in industrial motion control applications. Delivering a rated power of 1.2 kW and a nominal torque of 4.5 Nm, this model ensures consistent operation with outstanding accuracy at speeds up to 3000 rpm. Featuring a naturally cooled design, a rotatable power connector, and a plain shaft with holding brake, this motor provides flexible installation and robust durability for continuous operation. The integrated absolute encoder with 24-bit + 12-bit multiturn resolution ensures precise position detection, while the DRIVE-CLiQ interface enables seamless communication within the SINAMICS drive system.
The SIMOTICS S-1FK7 motor series represents Siemens’ latest generation of compact permanent-magnet synchronous motors engineered for versatility and maximum performance. These motors can be perfectly matched with SINAMICS S120 / S220 drives to form a powerful automation system with superior control capability. With multiple encoder and gearbox options, the series adapts effortlessly to a wide range of mechanical and motion control requirements. Each unit is designed for fanless operation, using the motor housing for heat dissipation, ensuring silent, energy-efficient performance with minimal maintenance.
Product Code: 1FK7044-4CF71-1CH2-ZQ31
Discover more Siemens products at Turll.com
| SKU / Model | 1FK7044-4CF71-1CH2-ZQ31 |
|---|---|
| Weight | 7.75 kg |
