1FK7044-4CH71-1QH2 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7044-4CH71-1QH2 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

The SIEMENS SIMOTICS S 1FK7044-4CH71-1QH2 is a premium synchronous motor engineered for high-performance industrial applications. With a rated power of 1.4 kW, voltage UDC 600V, and maximum torque M0 of 4.5 Nm at 4500 rpm, this compact motor ensures reliable operation across demanding environments. Its naturally cooled design and sturdy FRAME SIZE IMB 5 (IM V1, IM V3) provide excellent thermal management, while the rotatable power connector and integrated single-turn absolute encoder with Drive-CLiQ interface (ENCODER AS20DQI) support precise control and versatile integration into automation systems.

Overview

The SIMOTICS S-1FK7 series motors are designed for compactness, efficiency, and adaptability. These permanent-magnet synchronous motors can be easily combined with SINAMICS S120 or S220 drive systems, creating highly functional and flexible drive solutions. Integrated encoder systems allow precise speed and position control, enabling optimal performance tailored to specific applications. The high overload capability of these motors ensures they maintain performance even under challenging conditions.

Benefits

• Space-saving installation thanks to extremely high power density.
• Versatile for a wide range of industrial applications.
• High dynamic response for tasks requiring fast and precise motion control.
• Robust closed-loop control even with varying load moments of inertia.
• Minimal commissioning effort, reducing setup and optimization time.

Applications

These motors are ideal for machine tools, robotic systems, material handling, and machines used in woodworking, glass, ceramics, and stone processing. They are also suitable for packaging, plastics, textile machines, printing machines, and auxiliary axes requiring precise and reliable motion control. The IP65 degree of protection, along with a flange rated at IP67, ensures durability in harsh industrial environments.

Download

Data Sheet (PDF)

Product Code: 1FK7044-4CH71-1QH2
