1FK7060-2AC71-1CG1 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7060-2AC71-1CG1 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

The SIEMENS SIMOTICS S 1FK7-CT synchronous motor model 1FK7060-2AC71-1CG1 delivers exceptional performance and versatility for modern industrial applications. With a nominal power of 1.1 kW, UDC of 600 V, and torque rating of 6 Nm, this compact motor ensures precise and reliable operation. Naturally cooled with IMB 5 design, it offers efficient heat dissipation without the need for external cooling systems, making it ideal for space-constrained installations. The rotatable power connector and 24-bit +12-bit multi-turn absolute encoder (Drive-CLiQ interface) enable seamless integration into high-precision automation systems.

These SIMOTICS S 1FK7 motors are engineered for flexible adaptation to a wide range of industrial tasks. Thanks to a smooth shaft and tolerance N design without holding brake, they maintain high operational efficiency while supporting IP65-level protection for demanding environments. The motors are fully compatible with SINAMICS S120/S220 drive systems, offering comprehensive speed and position control through integrated encoder technology. Available options, such as gearboxes and additional encoders, allow for optimal customization to suit the unique requirements of each application.

Overview

The SIMOTICS S‑1FK7 series combines compact design with high performance. Motors in this series provide space-saving installation and extremely high power density, making them suitable for universal industrial applications. The high dynamic variants offer extremely fast response times due to low rotor inertia, while high inertia models ensure robust control under variable load conditions. These motors are designed to minimize commissioning and optimization overhead, delivering reliable operation across diverse applications.

Benefits & Applications

• Compact and space-efficient design with high power output
• Wide range of motor variants suitable for numerous industries
• High dynamic models with fast response for precision machinery
• High inertia models for stable performance under variable load
• Minimal setup and disturbance compensation required
• Ideal for machine tools, robots, handling systems, and auxiliary axes
• Applications in packaging, printing, plastics, wood, ceramics, glass, and textile machinery

Download

Data Sheet (PDF)

Product Code: 1FK7060-2AC71-1CG1
