1FK7060-2AC71-1UB0 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7060-2AC71-1UB0 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

The SIEMENS SIMOTICS S synchronous motor 1FK7060-2AC71-1UB0 is a high-performance compact motor built for precision motion control in demanding automation environments. Designed with a rated power of 1.1 kW and a torque of 6 Nm, this motor ensures reliable operation with superior efficiency. It operates at a nominal speed of 2000 rpm and a DC link voltage of 600 V, delivering consistent power output for advanced industrial processes. The naturally cooled IMB 5 design (IM V1, IM V3) with a rotatable power connector and multi-pole resolver offers flexible installation, while the integrated DRIVE-CLiQ interface enables seamless communication within the SINAMICS drive system.

Built to the IP64 protection standard, the motor provides excellent durability against dust and moisture, making it suitable for continuous use in harsh environments. The compact housing design ensures minimal space usage while maintaining high power density, a hallmark of SIEMENS engineering excellence. The 1FK7060-2AC71-1UB0 features a shaft with feather key and optional holding brake, ensuring precision positioning and mechanical reliability across a wide range of automation systems.

Overview

The SIMOTICS S-1FK7 motor series represents a new generation of permanent-magnet synchronous motors known for versatility and adaptability. These motors can be perfectly matched with the SINAMICS S120 or S220 drive systems to form a powerful and flexible automation solution. Integrated encoder systems for speed and position feedback provide optimal control performance across industrial applications.

• Compact design with exceptional power density for space-saving installation
• Available in multiple mechanical configurations and encoder options
• Optimized heat dissipation for efficient natural cooling
• High overload capability and reliable continuous operation
• Seamless integration with SIEMENS drive systems

Applications and Benefits

The 1FK7060-2AC71-1UB0 is ideal for machine tools, robotic arms, packaging, and textile machines. It provides smooth dynamic control for handling systems and precise positioning tasks in production automation. With outstanding mechanical rigidity and dynamic performance, it enhances productivity and process accuracy. The motor’s flexibility allows use in wood, glass, ceramics, and printing machinery, supporting both high-speed and high-torque operations with minimal commissioning effort.

Download

Data Sheet (PDF)

Product Code: 1FK7060-2AC71-1UB0
